ARBAY2-160/LC/8CPT2
ARBAY2-160/LC/8CPT2 large main
  • High efficiency. Low price.
  • Ideal for industrial warehouse spaces
  • 100,000 hour LED lifespan
  • 5-Year, limited warranty
 View Technical Specs
View Price & Availability
Performance
Watts 160W
Color Temp 5000K (Cool)
Lumens 23,276 lm
Efficacy 145.9
Color Accuracy 83 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V 1.32A
208V
240V
277V
Input Watts 159.5W
Dimensions
Link to Dimension Drawing

Weight: 13.8 lbs

Technical Specifications
Compliance
UL Listed
Suitable for damp locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNAlm-79 andlm-80.
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: P0QH55ZN
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
LED Characteristics
LEDs
Multi-chip, high-output, long-life LEDs
Construction
Operating Temperature
-4°F(-20°C) to 122°F ( 50°C)
Electrical
Driver
Class 2, Constant Current, 120-277V, 50/60 Hz, 120V: 1.32A, 208V: 0.77A, 240V: 0.67A, 277V: 0.58A
THD
3.84% at 120V, 6.36% at 277V
Power Factor
99.9% at 120V, 97.2% at 277V
