ARBAY3-275/LC/E2
ARBAY3-275/LC/E2 large main
  • High efficiency. Low price.
  • Ideal for industrial warehouse spaces
  • 100,000 hour LED lifespan
  • 5-Year, limited warranty
 View Technical Specs
View Price & Availability
Performance
Watts 275W
Color Temp 5000K (Cool)
Lumens 39,685 lm
Efficacy 143
Color Accuracy 83 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V 2.25A
208V 1.30A
240V 1.12A
277V 1.00A
Input Watts 277.6W
Dimensions
Link to Dimension Drawing

Weight: 18.7 lbs

Technical Specifications
Compliance
UL Listed
Suitable for damp locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNAlm-79 andlm-80.
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: P6Q8WDOE
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
LED Characteristics
LEDs
Multi-chip, high-output, long-life LEDs
Construction
Operating Temperature
-4°F(-20°C) to 122°F ( 50°C)
Electrical
Driver
Class 2, Constant Current, 120-277V, 50/60 Hz, 120V: 2.25A, 208V: 1.30A, 240V: 1.12A, 277V: 1.0A
THD
3.73% at 120V, 7.29% at 277V
Power Factor
99.9% at 120V, 95.1% at 277V
