ARBAY4-360/480/SP10

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

ARBAY4-360/480/SP10

High efficiency. Low price.

Ideal for industrial warehouse spaces

100,000 hour LED lifespan

5-Year, limited warranty

View Technical Specs

View Price & Availability

Performance

Watts	360W
Color Temp	5000K (Cool)
Lumens	50,696 lm
Efficacy	149.1
Color Accuracy	83 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V
208V
240V
277V
Input Watts	340W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 23.6 lbs

Technical Specifications

Compliance

UL Listed

Suitable for damp locations

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

DLC Listed

This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PKEILEOZ

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

LED Characteristics

LEDs

Multi-chip, high-output, long-life LEDs

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Construction

Operating Temperature

-20°C (-4°F) to 50°C (122°F)

Housing

22 gauge die formed with white powder coat finish. Y Hooks included for easy chain or cable mounting.

Reflector

White painted, reflective, die formed painted steel

Lens

Polycarbonate lens

Finish

Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

Installation

Mounting

V hooks and optional pendant mounting. AEROBAY® comes with two 42" chains.

Electrical

Driver

Class 2, Constant Current, 50/60 Hz, 480V: 0.74A

THD

8.96% at 480V

Power Factor

98% at 480V

Surge Protection

10kV

Other

Replacement

Replaces 1000W MH

5-Year Limited Warranty

The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
