• High output, high efficiency LED high bay
  • Bi-level and dimming models available when installed with pendant by others
  • Polyshield and wire guard accessories available for additional protection
  • 100,000-hour lifespan
  • 5-Year, No-Compromise Warranty
View Technical Specs
Performance
Watts 104W
Color Temp 4000K (Neutral)
Lumens 15,049 lm
Efficacy 123 lm/W
Color Accuracy 75 CRI
L70 Lifespan 100,000 hours
Type Constant Current
120V 1.03A
208V 0.65A
240V 0.56A
277V 0.49A
Input Watts 122W
Dimensions
Link to Dimension Drawing

Weight: 28.3 lbs

Technical Specifications
Other
BAYLED104 with Bi-Level Operation
Allows 50% and 100% output modes
Equivalency
Replaces 320 Watt Metal Halide
Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Buy American Act Compliance
RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
Compliance
UL Listed
Suitable for damp locations with cord and hook. Suitable for wet locations with 3/4" pendant stem.
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
DLC Listed
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PBU906T5
LED Characteristics
LEDs
Multi-chip, high-output, long-life LEDs
Color Consistency
3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Color Stability
LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Performance
Lifespan
100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Construction
Ambient Temperature
Suitable for use in up to 55°C (131°F)
Thermal Management
Superior heat sinking with external Air-Flow fins
Housing
Precision die-cast aluminum housing and door frame with 3-foot 600V power cord
Mounting
Heavy-duty 3/4" NPS hook and 3-foot safety chain; is also 3/4" pendant mount-capable (pendant by others)
Recommended Mounting Height
30 ft
Lens
Tempered glass
Reflector
Specular vacuum metallized polycarbonate
Gaskets
High-temperature silicone
Finish
Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Electrical
Drivers
Constant Current, 800mA, Class 2 with 6 kV surge protection, 100-277VAC, 50/60 Hz
THD
8.21% at 120V, 9.75% at 277V
Power Factor
99.5% at 120V, 93.8% at 277V
