BOA2LED-40N

Spec Sheet Instructions Spec Sheet

BOA2LED-40N

2 ft. Recessed Linear Slot Finishing includes LED, gear tray and lens

Offers a trimless design for a seamless appearance

3-step binning for color consistency

0-10V dimming, standard

100,000-Hour LED lifespan

View Technical Specs

View Price & Availability

Performance

Watts
Color Temp	4000K (Neutral)
Lumens
Efficacy
Color Accuracy	84 CRI
L70 Lifespan	100,000 Hours

Type
120V
208V
240V
277V
Input Watts

Dimensions

Weight: 1.8 lbs

Technical Specifications

Compliance

UL Listed

Suitable for damp locations. Recommended for indoor use only.

IC Rated

Suitable for direct contact with insulation

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Optical

Reflector

40° reflector

Aperture

2.5"

LED Characteristics

LEDs

Discrete LEDs on PCB board

Color Consistency

3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to Shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Performance

Lifespan

100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Construction

Lens

High-transmission, microprismatic acrylic lens for smooth light distribution and uniformity

Green Technology

Mercury and UV free. RoHS-compliant components.

Other

Recessed Finishing Section

This Recessed Finishing Section must be ordered with Recessed Rough-In Housing in order to make a complete fixture. See here for 2 ft Recessed Rough-In.

Electrical

Drivers

120 - 277V, 0 - 10V dimming down to 10%, 93.7% power factor, 1 kV surge protection
