• Mounts directly into ceiling, no housing required
  • Field-adjustable "set and forget" color temperature
  • High-performance LEDs for commercial applications
  • Meets air-tight requirements
  • 0-10V dimming, see Dimmer Compatibility List
  • Suitable for wet and damp locations
  • Replacement for traditional compact fluorescent recessed downlights
View Technical Specs
Performance
Watts 12/9/07W
Color Temp 3000K/3500K/4000K/5000K
Lumens 1000/800/600 lm
Efficacy 83/89/86 lm/W
Color Accuracy 90 CRI
L70 Lifespan 50,000 Hours
Type Constant Current
120V .11A
208V .06A
240V .05A
277V .05A
Input Watts 12/9/07W
Dimensions
Link to Dimension Drawing

Weight: 0.7 lbs

Technical Specifications
Performance
Product Type
Commercial Downlight
Description
Wattage and CCT selectable commercial downlights for new construction and retrofit applications.
Wattage Equivalency
14/11/8W CFL
Input Wattage
12/9/7W
Lumens
12W: 3000K @ 1,000lm; 3500K @ 1,040lm; 4000K @ 1,040lm; 5000K @ 1,020lm
9W: 3000K @ 800lm; 3500K @ 830lm; 4000K @ 830lm; 5000K @ 820lm
7W: 3000K @ 600lm; 3500K @ 630lm; 4000K @ 630lm; 5000K @ 620lm
Efficacy
12W: 3000K @ 83lm/W; 3500K @ 87lm/W; 4000K @ 87lm/W; 5000K @ 85lm/W
9W: 3000K @ 89lm/W; 3500K @ 92lm/W; 4000K @ 92lm/W; 5000K @ 91lm/W
7W: 3000K @ 86lm/W; 3500K @ 90lm/W; 4000K @ 90lm/W; 5000K @ 89lm'W
L70 Lifespan
50,000-Hour LED lifespan based on IES LM-70 results
Electrical
Driver
Constant Current, Class 2, 60 Hz, 120V-277V, 120V: 0.11A, 277V: 0.05A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
≤20%
Power Factor
≥0.9
Dimmable
Yes, 0-10V dims down to 10%. See Dimmer Compatibility List.
Input Voltage
120-277V
Operating Frequency
50/60Hz
Input Current @ 120V (mA)
110mA
Input Current @ 208V (mA)
60mA
Input Current @ 240V (mA)
315mA
Input Current @ 277V (mA)
46mA
Operating Temperature
-4°F to 104°F (-20°C to 40°C)
Flicker
≤30%
Color Temperature
Field Adjustable via dip switch 3000/3500/4000/5000K
LED Characteristics
Color Accuracy (CRI)
>90 CRI
R9 Value
High color performance with R9 greater than or equal to 50
Color Consistency
4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Color Stability
LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Installation
Mounting
Recessed
Construction
Size
4"
Shape
Round
Finish
White
Enclosure Material
Metal
Trim Style
Smooth
Lens
Polycarbonate light diffuser distributes light evenly and smoothly for general lighting applications
Cut Out Template Size
4 5/16"
IC Rated
Suitable for direct contact with insulation
Compliance
Listings
UL Listed, UL Classified
Environment
Suitable for use in dry, damp, and wet environments.
Air Tight
Housing certified Air Tight as per ASTM E283
Energy Star Approved
This product is ENERGY STAR® Version 2.2 Certified.
Energy Star ID
2389601
DLC Listed
No.
There is no product category on the Design Lights Consortium (DLC) Qualified Products List for this lamp to qualify under.
Certification Model Number
DLC0054(CRLEDFA-4R-12S-9CCT-UNV-WS)
T20 Compliant
Not compliant
California Title 24 JA8 Compliant
Can be used to conform with the requirements of California Title 24 Part 6
California Energy Commission (CEC) Status
Lawful for Sales in California
NEC Compliant
Suitable for use in closets. Compliant with NEC Sec. 410.16 (A)(1) and 410.16 (C3).
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
RoHS
Mercury and UV free. RoHS-compliant components.
FCC
Complies with Part 15 of the FCC Rules
Trade Agreements Act Compliant
This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act
Other
Accessories
DLPLATE/WFR3468/NB
Mounting Plate w/nailer bar

DL4-6GOOF/R/P/CRLEDFA
Commercial Downlight 4"-6" Goof Ring

DLTRIM/CRLEDFA4R-BNS
4" Smooth Brushed Nickel Color Trim

DLTRIM/CRLEDFA4R-BRS
4" Smooth Bronze Color Trim

DLTRIM/CRLEDFA4R-BS
4" Smooth Black Color Trim

DRI-25-EMGR-DC
Emergency Back up Driver

DRI-21-EMGR-DC-D10
Emergency backup driver
Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Note
All values are typical (tolerance +/- 10%)
Buy American Act Compliance
RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
