DSK8R229FA120WS

Spec Sheet IES File Dimmer Compatibility List LM79 Instructions Spec Sheet EZ Layout

DSK8R229FA120WS

Low profile back-lit design made of durable thermoplastic housing with frosted lens

New construction or retrofit applications

Installs on standard junction boxes

Suitable for indoor/outdoor use in dry, damp, and wet locations

Suitable for use in closets when installed in accordance with NEC guidelines

Dimmable down to 5% on compatible dimmers, see Dimmer Compatibility List

View Technical Specs

View Price & Availability

Performance

Watts	22W
Color Temp	2700/3000/3500/4000/5000K
Lumens	2,200 lm
Efficacy	100
Color Accuracy	90 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current
120V	0.20A
208V
240V
277V
Input Watts	22W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 1.4 lbs

Technical Specifications

Performance

Description

5CCT Selectable Low-profile, surface-mount Disk for new construction and retrofit applications. Ideal for use in a variety of applications including hallways, bathrooms, stairways, closets, and canopies.

Product Type

Surface & Flush Mounts

Input Wattage

22W

Lumens

2,000lm

Efficacy

90.9lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IES LM-70 results

Compliance

UL Listed

Suitable for wet locations

UL Classified

Yes

Energy Star Approved

ENERGY STAR® Version 2.2 Certified

California Title 20 Compliant

Can be used to conform with the requirements of California Title 20

California Title 24 JA8 Compliant

Can be used to conform with the requirements of California Title 24 Part 6.

Energy Star ID

3550145

Electrical

Dimming Driver

TRIAC compatible dimmer with dimming as low as 10%.

THD

≤20%

Power Factor

≥0.9

Flicker

≤30%

Input Voltage

120V

Operating Frequency

60Hz

Construction

Material

Plastic

Trim Style

Smooth Trim

Shape

Round

Operating Temperature

-4°F(-20°C) to 104°F (40°C )

Size

Installation

Base Type

E26 Edison

Mounting

Surface and recessed mount

LED Characteristics

R9 Value

High color performance with R9 greater than or equal to 50

Other

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
