• Durable thermoplastic design
  • Emergency light with 90-minute battery backup
View Technical Specs
Dimensions
Link to Dimension Drawing

Weight: 0.8 lbs

Technical Specifications
Performance
Product Type
Emergency Unit
Description
Emergency Thermoplastic Unit
Input Power
1.8W
Lumens
65lm
Lumens (per fixture)
130lm
Electrical
Power Factor
0.7@120V; 0.6@277V
Input Voltage
Dual 120/277 Voltage
Frequencies
60 Hz
Input Current @ 120V (mA)
22mA
Input Current @ 277V (mA)
10mA
Dual Voltage Circuit Operation
No
Operating Temperature
32°F to 122°F (0°C to 50°C)
Emergency Illumination
90 minutes
Battery Type
Nickel Cadmium
Battery Voltage
3.6V
Recharge Time Required
24-hours
Battery Operating Temperature
32°C to 122°C (0°F to 50°F)
Storage Temperature
68°F to 86°F (20°C to 30°C)
Storage Shelf Life
3 years before the initial charge. 5 years after initial charge.
Self Diagnostics
No, manual test only
Remote Test Switch
No
Installation
Mounting Method
Back/Conduit
Mounting Type
Wall Mount
Maximum Mounting Height (ft.)
8 ft
Emergency Egress Coverage(ft) Mounting at height of 7.5ft
14 ft x 3 ft mounted @ 7.5 ft
Spacing Criteria for Emergency Egress
17.5 ft on center assuming 7.5 ft mounting height with egress path 3 ft out
Cold Weather Rated
No
Construction
Shape
Rectangle
Housing Material
Thermoplastic
Housing Color
White
Remote Capacity
No
No. of Heads
2-Lamp Heads
Head Shape
Square
Compliance
Listings
UL924 Listed
Environment
Suitable for indoor use in dry and damp environments
IP Rating
Indoor
Certification Model Number
LEDR-1-HL
T20 Compliant
Not Title 20 Compliant
California Title 24 JA8 Compliant
Not applicable
California Energy Commission (CEC) Status
Lawful for Sales in California
FCC
Complies with Part 15 of the FCC Rules
Other
5-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Battery is prorated.
