ENTRA

14W 3000/4000/5000K

100,000-hour LED Life

120-277V

Low-profile and ADA compliant

Compatible with RAB specified 0-10V dimming system

5-Year, no-compromise warranty

View Technical Specs

View Price & Availability

Performance

Watts	14/11/7W
Color Temp	3000/4000/5000K
Lumens	825-1,791 lm
Efficacy	119.6-133.7 lm/W
Color Accuracy	84-86 CRI
L70 Lifespan	100,000 Hours

Type	Constant
120V	0.12A
208V	0.07A
240V	0.06A
277V	0.05A
Input Watts	6.9-13.4W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 4.0 lbs

Technical Specifications

Field Adjustability

Field Adjustable

Field Adjustable Light Output:
14/11/7W (factory default: 14W)
Color temperature selectable by 3000K, 4000K and 5000K (factory default: 4000K)

Compliance

UL Listed

Suitable for wet locations

ADA Compliant

Meets ADA Requirements for wall-mounted luminaires.

Trade Agreements Act Compliant

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

Electrical

Driver

14W: Constant Current, Class 1, 120-277V, 50/60 Hz, 120V: 0.12A, 208V: 0.07A,240V: 0.06A, 277V: 0.05A
11W: Constant Current, Class 1, 120-277V, 50/60 Hz, 120V: 0.10A, 208V: 0.06A,240V: 0.05A, 277V: 0.04A
7W: Constant Current, Class 1, 120-277V, 50/60 Hz, 20V: 0.06A, 208V: 0.04A,240V: 0.04A, 277V: 0.03A

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

5.46% at 120V, 10.99% at 277V

Power Factor

99.5% at 120V, 94.5% at 277V

Aux Power Supply

Yes

Dim to Off

Yes

Photocell

Integrated photocell included with on/off switch

Surge Protection

4 kV

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

LED Characteristics

LEDs

Long-life, high-efficacy, surface-mount LEDs

Color Consistency

7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Construction

Housing

Sheet metal

Lens

Bio-based Polymethy Methacrylate (PMMA) lens

Reflector/Tray

Aluminum

Gaskets

High-temperature silicone

Cold Weather Starting

The minimum starting temperature is -40°F (-40°C)

Maximum Ambient Temperature

Suitable for use in up to 122°F (50°C)

Green Technology

Mercury and UV free. RoHS-compliant components.

Finish

Formulated for high durability and long-lasting color

Installation

Mounting

Wall mount

Other

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
