EXT-GLW/RGB

Spec Sheet Sell Sheet Folleto (Español) Family Spec Sheet Spec Sheet

EXT-GLW/RGB

10 ft Extension cord for GLW, 120V

No bulbs included

Ideal for patios, restaurants, events, and retail spaces

View Technical Specs

View Price & Availability

Performance

Watts	11W
Color Temp	Tunable White 1800-3000K
Lumens	264 lm
Efficacy	24
Color Accuracy	>80 CRI
L70 Lifespan	15,000 Hours

Type
120V
208V
240V
277V
Input Watts	11W

Dimensions

Weight: 3.0 lbs

Technical Specifications

Lightcloud

Lightcloud Blue

Lightcloud Blue is a Bluetooth® Mesh lighting control system designed for fast setup and flexibility. Install quickly with no gateways, hubs, or additional control wiring. Start with a single device and easily scale to control entire buildings.
Learn more at rablighting.com/lcb.

DLC system - N1XMLOEATBA (Interior); NHCZ2BIA17L (Exterior)

Gateway Required

Communication Protocol

Bluetooth Mesh

SmartShift

SmartShift Ready to easily configure automated lighting profiles to automatically adjust brightness and color temperature for circadian and aesthetic needs.

Light Shows

Yes. Dynamic RGB light shows with customizable effects and color sequences using the Lightcloud Blue mobile app.

Range

Indoor: Up to 60 feet between standard building materials. Building materials such as brick, concrete, and steel construction may require additional Lightcloud Blue devices to extend around an obstruction; Up to 200 feet clear line of sight.

Outdoor: Up to 200 feet clear line of sight; Up to 120 feet around corners

Spacing Criteria

Lightcloud Blue devices should be placed within the specified range to communicate within the Bluetooth Mesh network. Building materials such as brick, concrete, and steel construction or heavy vegetation, bushes or trees may require additional Lightcloud Blue devices to extend around an obstruction.

Sensor Settings

Remote Control Accessory

Yes, with additional devices, sold separately. Small projects use Nano to link with Amazon Alexa or Google Home for wireless control using those apps. Larger projects require one XDIM Bridge per Area plus a Gateway for full remote access via Lightcloud web portal or mobile app.

Performance

Product Type

Extension Decorative String Light, Smart

Description

25 ft Extension for GLW/RGB String Light (12 bulbs)

Input Wattage

11W

Lumens (Nominal)

264lm

L70 Lifespan

15,000-Hour LED lifespan based on IES LM-70 results

Optical

Fixture Efficacy

24lm/W

Electrical

Dimmable

Yes, using Lightcloud Blue. This product will not operate properly when connected to a standard (incandescent) dimmer or dimming control.

Input Voltage

24V

Construction

Operating Temperature

-4°F(-20°C) to 104°F (40°C )

Length

25 ft

Bulbs per String

Max Run Length

150 ft

Shape

S14

Finish

Black cord with clear filament style bulbs

Enclosure Material

Glass

Lens Finish

Clear

LED Characteristics

Beam Angle

120°

Color Temperature

Default: 3000K
Adjustable using the Lightcloud Blue mobile app
Tunable White 1800 - 3000K

Color Tuning

Yes, 16+ million colors using Lightcloud Blue

Color Accuracy (CRI)

>80 CRI

Natural Spectrum

R9 Value

High color performance with R9 greater than 0

Color Consistency

<4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Installation

Mounting

Connects using 5-pin twist lock connector

Base Type

5-pin Twist lock connector

Replaceable Bulbs

Individual bulbs are not replaceable

Compliance

Environment

Suitable for use indoors and outdoors in dry, damp, or wet environments.

Certification Model Number

EXT-GLW/RGB

California Title 24 JA8 Compliant

California Energy Commission (CEC) Status

Lawful for Sales in California

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15 of the FCC Rules

Other

Compatible Products

GLW/RGB
50 ft. Decorative string light, RGBW

3-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
