Suitable for damp locations

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PEDX3ISX

60,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Equivalent to (4)F32T8 or (4)F28T5

Suitable for use in up to -30°C (-22°F) to 50°C(122°F)

Suitable for insulated ceilings

Frosted polystyrene

Lightweight aluminum housing, steel pan and junction box

Standard integral T-bar clips secure the fixture to T-bars and prevent T-system separation

Formulated for high durability and long-lasting color

Mercury and UV free. RoHS-compliant components.

Integrated/embedded networked lighting control, luminaire-level lighting control. Fixture, Zone, and plug-load control from one powerful device. LLLC - capable of switching, 0-10Vdimming, power/energy monitoring. Can also be used to extend the range of the Lightcloud mesh network communication protocols. Offers the capability to set the maximum light output to a less-than-maximum state of an individual luminaire at the time of installation or commissioning. The High-End trim functionality is field reconfigurable via the Lightcloud mesh network communication protocols. The Lightcloud controller can be attached to the fixture, junction box, or electrical panel.
DLC system - N1XMLOEATBA
Learn more at www.lightcloud.com

Long-life, high-efficacy, surface-mount LEDs

Constant Current, Class 2, 50/60 Hz, 120-277V, 120V: 0.25A, 208V: 0.20A, 240V: 0.13A, 277V: 0.12A

7.76% at 120V, 9.61% at 277V

98.9% at 120V, 90.8% at 277V

Battery backup will operate the LED Lamp for 90 minutes if power fails. Wired for 120V-277V.

0.43

Recessed ceiling

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
