EZPAN1X4-40YN/D10/E2

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

Perfect for shallow plenums

Even and diffuse ambient illumination, ideal for spaces where glare-free lighting is required

0-10V dimmable driver, standard

View Technical Specs

View Price & Availability

Performance

Watts	40W
Color Temp	3500K (Warm Neutral)
Lumens	4,691 lm
Efficacy	118.3
Color Accuracy	83 CRI
L70 Lifespan	60,000 Hours

Type	Constant Current
120V	0.34A
208V	0.20A
240V	0.17A
277V	0.15A
Input Watts	39.6W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 10.6 lbs

Technical Specifications

Compliance

UL Listed

Suitable for damp locations

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

CCEA Compliant

Luminaire Requirements used in Environmental Air Space per the electrical code specification of the City of Chicago

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PXL2WSUJ

Performance

Lifespan

60,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Wattage Equivalency

Equivalent to (4)F32T8 or (4)F28T5

Construction

Maximum Ambient Temperature

Suitable for use in up to -30°C (-22°F) to 50°C(122°F)

IC Rated

Suitable for insulated ceilings

Lens

Frosted polystyrene

Housing

Lightweight aluminum housing, steel pan and junction box

Installation

Standard integral T-bar clips secure the fixture to T-bars and prevent T-system separation

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

LED Characteristics

LEDs

Long-life, high-efficacy, surface-mount LEDs

Electrical

Driver

Constant Current, Class 2, 50/60 Hz, 120-277V, 120V: 0.34A, 208V: 0.20A, 240V: 0.17A, 277V: 0.15A

THD

8.42% at 120V, 6.23% at 277V

Power Factor

99.1% at 120V, 94.5% at 277V

Battery Backup

Battery backup will operate the fixture for 90 minutes if power fails. Wired for 120-277V.

Battery Backup Light Loss Factor

0.33

Installation

Mounting

Recessed ceiling

Other

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
