EZPANFA1X4/D10/LCBS

Spec Sheet IES File Photometrics Report Instructions Spec Sheet EZ Layout

EZPANFA1X4/D10/LCBS

100,000-hour LED Lifespan

DLC Standard Listed

5-Year, No-Compromise Warranty

View Technical Specs

View Price & Availability

Performance

Watts	30W
Color Temp	Field Adjustable
Lumens	2960-4569 lm
Efficacy	107.4-119.5 lm/W
Color Accuracy	79-81 CRI
L70 Lifespan	75,000 Hours

Type	Constant Current
120V	0.26A
208V	0.15A
240V	0.13A
277V	0.12A
Input Watts	25.6-40.5W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 11.6 lbs

Technical Specifications

Field Adjustability

Field Adjustable

Field Adjustable Light Output:
1' x 4': 40W/30W/25W(factory default 30W)
Color temperature selectable by 3500K, 4000K and 5000K (factory default 4000K)

Compliance

UL Listed

Suitable for damp locations

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

CCEA Compliant

Luminaire Requirements used in Environmental Air Space per the electrical code specification of the City of Chicago

Trade Agreements Act Compliant

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

Performance

Lifespan

75,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

LED Characteristics

LEDs

Edge-lit design with long-life, high-efficacy LEDs

Construction

Operating Temperature

-30°C (-22°F) to 40°C (104°F)

Lens

Frosted polystyrene

IC Rated

Suitable for insulated ceilings

Housing

Lightweight aluminum housing

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

Installation

Mounting

Recessed ceiling

Sensor Settings

Default Setting

Uncommissioned State:
Sensor Status: Enabled
Motion Sensitivity: High
Brightness when triggered: 100%
Hold time: 1 minute
Standby to dim: 20%
Standby time: 1 minute
When vacant: Off

Commissioned State:
Sensor Status: Disabled, once enabled the following default are set.
Motion Sensitivity: High
Brightness when triggered: Last on status
Hold time: 20 minutes
When vacant: Off

Sensing Type

Occupancy or Vacancy

Occupied Actions

On or On at a Dim Level

Vacant Options

Off or On at a Dim Level

Occupancy Timeout

1 minute to 240 minutes

Daylight Sensing

The sensor will determine to trigger the light(s) on or not based on the daylight threshold level set in the Lightcloud Blue mobile app.

Daylight Threshold

150 lux to 1500 lux

Other

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Electrical

THD

5.48% at 120V, 11.22% at 277V

Power Factor

99.5% at 120V, 92.9% at 277V
