HID-100-EX39-850-BYP-ADJ

Spec Sheet Sensor Compatibility List Photometrics Report Instructions FCC Caution Spec Sheet

Replacement for traditional Metal Halide or High Pressure Sodium HID Lamps up to 400W

Multiple angle configurations ideal for low/high bay, shoebox, and post top applications

Active Cooling: Internal sensor overheat and engaged will automatically reduce output to 70% rated wattage until the sensor cools and will light up again to 100%

Integral Driver enables lamp to be wired directly to line voltage without need for an external driver or ballast

Rated for use in enclosed and open fixtures in dry or damp locations

4kV surge protection built in

50,000 hour Lifespan

Environmentally friendly, no mercury used

UL Listed, DLC Listed

5 Year No Compromise Warranty

Lamp includes on board low-voltage AUX port for lamp level sensor accessories

Compatible with RAB specified 0-10V dimming system

View Technical Specs

View Price & Availability

Performance

Watts	100W
Color Temp	5000K
Lumens	15,000 lm
Efficacy	150
Color Accuracy	80 CRI
L70 Lifespan	50,000 Hours

Input Voltage	100-277V
Power Factor	>0.9
Flicker	N/A
THDi	<20%

Dimensions

Weight: 3.5 lbs

Technical Specifications

Performance

Product Type

HID Replacement

Input Wattage

100W

Lumens

15,000lm

Efficacy

150lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Wattage Equivalency

400W

Dimming

Compatible with RAB specified 0-10V dimming system. Dimming capabilities were tested and verified on Legrand RH4FBL3PTC 0-10V dimming system.

LED Characteristics

Color Accuracy (CRI)

Color Temperature

5000K

Construction

Bulb Shape

Post Top/ High Bay / Shoebox

Enclosure Material

Polycarbonate & Metal heat sink

Housing Finish

White

Installation

Base Type

EX39

Installation Method

UL Type B, Ballast Bypass

Burning Position

Universal

Electrical

THD

<20%

Power Factor

>0.9

Input Voltage

100-277V

Operating Frequency

60 Hz

Operating Temperature

-30°C to 60°C

Surge Protection

4 kV

Other

Technology EQ

Metal Halide or High Pressure Sodium

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Compliance

Listings

UL Listed, UL Classified

Environment

Damp / Enclosed

IP Rating

IP64

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15B of the FCC Rules

Certification Model Number

H10030(HID-100-EX39-850-BYP-ADJ)

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PLWCZWE9K4Y6
