Performance
| Watts | 160W |
| Color Temp | 5000K (Cool) |
| Lumens | 20,996 lm |
| Efficacy | 132.4 lm/W |
| Color Accuracy | 86 CRI |
| L70 Lifespan | 50,000 Hours |
| Type | Constant Current |
| 120V | 1.50A |
| 208V | 0.87A |
| 240V | 0.75A |
| 277V | 0.65A |
| Input Watts | 158.6W |
Dimensions
Weight: 6.0 lbs
Technical Specifications
Compliance
UL Listed
Suitable for damp locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
Trade Agreements Act Compliant
This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act
DLC Listed
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PVWC2J26
DLC Product Code: PVWC2J26
Performance
Lifespan
50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Tilt Angle
0° - 158.6W; 20,996 lumens
15° - 158W; 20,754 lumens
27° - 158.4W; 20,977 lumens
39° - 156.6W; 20,946 lumens
50° - 159.1W; 21,077 lumens
15° - 158W; 20,754 lumens
27° - 158.4W; 20,977 lumens
39° - 156.6W; 20,946 lumens
50° - 159.1W; 21,077 lumens
Wattage Equivalency
Equivalent to 400W Metal Halide
Electrical
Driver
Constant Current, Class 2, Class P, 120-277V, 50/60 Hz, 120V: 1.50A, 208V: 0.87A, 240V: 0.75A, 277V: 0.65A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
6.55% at 120V, 13.3% at 277V
Power Factor
99.8% at 120V, 94.2% at 277V
Surge Protection
2.5kV
LED Characteristics
LEDs
Long-life, high-efficacy, discrete, surface-mount LEDs
Color Consistency
7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Construction
Cold Weather Starting
The minimum starting temperature is -20°C (-4°F)
Maximum Ambient Temperature
Suitable for use in up to 50°C (122°F)
Housing
Polycarbonate and ABS (PC/ABS)
Mounting
V-hooks and optional pendant mounting
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Other
5 Yr Limited Warranty
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Buy American Act Compliance
RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
