• Wireless Control & Configuration
  • Cloud-based Management
  • Dual Power Monitoring
  • Tamper Resistant
  • Current Limiting 20A
  • Scenes, Schedules, Occupancy/Vacancy Control (Sensor Required)
View Technical Specs
Dimensions
Link to Dimension Drawing

Weight: 0.3 lbs

Technical Specifications
Compliance
UL Listed
Suitable for indoor
DLC Listed
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities
Electrical
Installation
All Lightcloud components should be installed by a licensed electrician in accordance with local codes.
Input Voltage
125VAC
Frequencies
60 Hz
Electrical Ratings
20 A @ 125VAC
Load Switching Capacity
Tungsten: 1500W (12.5A)
CFL and LED (Electronic Ballast): 5A
Construction
Operating Temperature Range
-4°F - 104°F (-20°C - 40°C)
Storage Temperature Range
-40°C to 40°C
Maximum Relative Humidity
80%
Terminal
15A - 14 AWG
20A - 12AWG
Copper Wires Only
Installation
Mounting
Single or multi-gang junction box
Wireless Range
Line-of-Site
1000 ft
Obstructions
100 ft
Other
Warranty
10-year full hardware warranty with 100% repair/replacement coverage for all properly installed devices. See Lightcloud Warranty Terms.
