LOT4T65Y/D10/5PR

Spec Sheet Instructions Spec Sheet

DISCONTINUED

LOT4T65Y/D10/5PR

100,000-hour LED lifespan

Type IV distribution

View Technical Specs

Performance

Watts	65W
Color Temp	3000K (Warm)
Lumens	7,684 lm
Efficacy	123.9 lm/W
Color Accuracy	73 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	0.55A
208V	0.33A
240V	0.29A
277V	0.25A
Input Watts	62W

Dimensions

Weight: 20.9 lbs

Technical Specifications

Compliance

UL Listed

Suitable for wet locations

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PTFWA65X

Electrical

Driver

Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.55A, 208V: 0.33A, 240V: 0.29A, 277V: 0.55A

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

7.85% at 120V, 7.48% at 277V

Power Factor

99.7% at 120V, 94.3% at 277V

5-Pin Receptacle

ANSI C136.41 5-pin receptacle, compatible with wireless control systems

Performance

Lifespan

100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Construction

IES Classification

The Type IV distribution (also known as a Forward Throw) produces a semicircular distribute, and is especially suited for mounting on sides of buildings or walls and perimeter of parking areas

Effective Projected Area

EPA = 0.8
