NDICLED3S-15DYHC-TL-CP
NDICLED3S-15DYHC-TL-CP
- 3-in-1 housing accommodates downlight, adjustable or wall washer
- Universal driver supports TRIAC, ELV and 0-10 dimming
- IC-rated, Certified Air Tight
- 100,000-hour LED lifespan
- 5-Year, No-Compromise Warranty
Performance
| Watts | 15W |
| Color Temp | 3000K (Warm) |
| Lumens | See Table Below* lm |
| Efficacy | |
| Color Accuracy | 90 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | 0.12A |
| 208V | 0.08A |
| 240V | 0.07A |
| 277V | 0.06A |
| Input Watts | 15W |
Dimensions
Weight: 10.4 lbs
Technical Specifications
Compliance
UL Listed
Suitable for wet locations in a covered ceiling
CCEA Compliant
Luminaire Requirements used in Environmental Air Space per the electrical code specification of the City of Chicago
IC Rated
Suitable for direct contact with insulation
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Electrical
Driver
Constant Current, Class 2, 120-277V, 50/60Hz, 120V: 0.12A, 208V: 0.08A, 240V: 0.07A, 277V: 0.06A
Dimming Driver
Universal dimming driver supports TRIAC, ELV and 0-10V. See dimmer compatibility guide here.
