NDLED7R38Y/LC

Spec Sheet Master Specification Features Spec Sheet

NDLED7R38Y/LC

Universal driver is compatible with TRIAC, ELV and 0-10V dimmers

Lightweight design for easy installation and increased safety

100,000-Hour LED lifespan

View Technical Specs

View Price & Availability

Performance

Watts	38W
Color Temp	3000K (Warm)
Lumens
Efficacy
Color Accuracy	82 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	0.31A
208V	0.19A
240V	0.17A
277V	0.14A
Input Watts	38W

Dimensions

Weight: 8.0 lbs

Technical Specifications

Installed with Lightcloud

Lightcloud is a commercial wireless lighting control system fully developed and supported by RAB. It's powerful and flexible, yet easy to use and install.

Learn More

Lightcloud

Lightcloud Controller Installed

Fixture, Zone, and plug-load control from one powerful device. Capable of switching, 0-10V dimming, power monitoring. Can also be used to extend the range of the Lightcloud mesh network. Attach to fixture, junction box, or electrical panel. Learn more at www.lightcloud.com

Compliance

UL Listed

Suitable for wet locations in a covered ceiling

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Electrical

Driver

Class 2, Constant Current, 50-60Hz, 900mA

Dimming

Universal dimming driver for 0-10V (at 120-277V), TRIAC or ELV (at 120V only). See dimmer compatibility guide here.

Surge Protection

6 kV

Construction

Housing Component

This component must be ordered with New Construction Downlights Trim Module in order to make a complete fixture.
See here for Retrofit Reflectors.

Housing

Formed galvanized steel construction

Cold Weather Starting

The minimum starting temperature is -22°F (-30°C)

Maximum Ambient Temperature

Suitable for use in up to95°F(35°C)

Lens

Diffusion lens for smooth and even light distribution

Reflector

Spun aluminum

Heat Sink

Die-cast aluminum with external fins for maximum heat dissipation

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

LED Characteristics

LEDs

Long-life, high-efficiency surface-mount LEDs with 3 step binning

Color Consistency

3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Other

10-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of ten (10) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Replacement

Replaces 50 Watt Metal Halide and 32 Watt CFL
