PLC-8.5-H-8FA-HYB

Spec Sheet Compatibility List Photometrics Report Instructions FCC Caution Spec Sheet

PLC-8.5-H-8FA-HYB

Field Adjustable 3 CCTs in 1 SKU (3000K, 3500K, 4000K)

Replaces 18W/26W/32W G24d & G24q CFL Lamps

Plug and Play on existing Magnetic CFL ballasts or can be wired directly to line voltage without need for an external driver or ballast

Compatible with G24d / GX24d & G24q / GX24q installations

Instant-on with no warmup, unlike CFLs

Lasts 5x longer than compact fluorescent lamps

Consumes up to 1/3 the energy of conventional CFL

Base rotates, direct light where needed on Horizontal models

50,000 hour Lifespan

Environmentally friendly, no mercury used

UL Listed, UL Classified

Rated for use in enclosed and open fixtures in dry or damp locations

Non-Dimmable

5 Year No Compromise Warranty

View Technical Specs

View Price & Availability

Performance

Watts	8W
Color Temp	3000/3500/4000K
Lumens	960/1020/1050 lm
Efficacy	113/120/123 lm/W
Color Accuracy	80 CRI
L70 Lifespan	50,000 Hours

Input Voltage	Type B - 120-277 / Type A - dependant on the
Power Factor	>0.9
Flicker	N/A
THDi	20

Dimensions

Weight: 0.2 lbs

Technical Specifications

Performance

Product Type

Compact

Input Wattage

8.5W

Lumens

960/1020/1050lm

Efficacy

113/120/123lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Wattage Equivalency

26W/32W G24d & G24q

LED Characteristics

Color Accuracy (CRI)

Color Temperature

3000/3500/4000K

Beam Angle

110°

Electrical

THD

20%

Power Factor

>0.9

Dimmable

Non-Dim

Input Voltage

120-277 Type B (Type A dependent on ballast)

Operating Frequency

50/60Hz

Operating Temperature

-20°C to 45°C (-4°F to 113°F)

Construction

Shape

PLC-Horizontal

Enclosure Material

Constructed from frosted, shatter-resistant polycarbonate

Housing Finish

White

Lens Finish

Frosted

Installation

Base Type

2-Pin G24d

Installation Method

UL Type A with Magnetic Ballasts & UL Type B (Dual Mode)

Burning Position

Horizontal

Other

Technology EQ

CFL

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Compliance

Listings

UL Listed, UL Classified

Environment

Damp / Open

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15B of the FCC Rules

Certification Model Number

T10200(PLC-8.5-H-8FA-HYB)
