PLED2X13MS2/BL

Spec Sheet Instructions Spec Sheet

PLED2X13MS2/BL

Reduce energy usage with motion sensor technology you can rely on

LED combined with mini sensor for an all-in-one lighting solution

Great for small spaces like utility closets and storage rooms

5-Year, No-Compromise Warranty

View Technical Specs

View Price & Availability

Performance

Watts	26W
Color Temp	5000K (Cool)
Lumens	2,006 lm
Efficacy	66 lm/W
Color Accuracy	69 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	0.26A
208V
240V
277V
Input Watts	30.4W

Technical Specifications

Other

Bi-Level Operation

Bi-Level option supplies a fixture with the sensor(s) wired to control only one fixture leaving the other fixture always on or available for timer or photo sensor control by customer. Two sets of labeled leads will be provided.

Compliance

UL Listed

Suitable for damp locations

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Installation

Recommended Mounting Height

8-10'

Mounting

3 mounting stems included. 6", 12" and 18" can be combined to achieve a maximum length of 36". 42" of wire supplied. The pendants thread into a hang-straight, leveling the fixture. Pendant outside diameter is 3/4". Threads are 1/4". Circular canopy included.

LED Characteristics

LEDs

(2) 13W Multi-chip high-output, long-life LED

Construction

Housing

Precision die-cast aluminum housing and lens framing

Electrical

Drivers (2)

Constant Current, Class 2, 100V-277V, 50/60 Hz, 4kv Surge Protection, 720mA, 100-240VAC 0.3-0.15 Amps, 277VAC 0.3 Amps, THD less than equal to 20%, Power Factor 97.5%.
