PLT-16.5-V-840-BYP

Replaces 18W/26W/32W G24d & G24q CFL Lamps

Ballast Bypass. Integral Driver enables lamp to be wired directly to line voltage without need for an external driver or ballast

Compatible with G24d / GX24d & G24q / GX24q installations

50,000 hour Lifespan

Environmentally friendly, no mercury used

UL Classified

Rated for use in enclosed and open fixtures in dry or damp locations

Non-Dimmable

5 Year No Compromise Warranty

View Technical Specs

View Price & Availability

Performance

Watts	16W
Color Temp	4000K
Lumens	1,900 lm
Efficacy	115
Color Accuracy	80 CRI
L70 Lifespan	50,000 Hours

Input Voltage	120-277V
Power Factor	>0.9
Flicker	N/A
THDi	20

Dimensions

Weight: 0.6 lbs

Technical Specifications

Performance

Product Type

Compact

Input Wattage

16.5W

Lumens

1,900lm

Efficacy

115lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Wattage Equivalency

42W G24d/G24q/Gx24q

LED Characteristics

Color Accuracy (CRI)

Color Temperature

4000K

Beam Angle

120°

Electrical

THD

20%

Power Factor

>0.9

Dimmable

Non-Dim

Input Voltage

120-277V AC

Operating Frequency

50/60Hz

Operating Temperature

-20°C to 45°C (-4°F to 113°F)

Construction

Shape

PLT-Vertical

Enclosure Material

Constructed from frosted, shatter-resistant polycarbonate

Housing Finish

White

Lens Finish

Frosted

Installation

Base Type

2-Pin G24d

Installation Method

UL Type B, Ballast Bypass

Burning Position

Vertical

Other

Technology EQ

CFL

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Compliance

Listings

UL Classified, UL Recognized

Environment

Damp / Open

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15B of the FCC Rules

Certification Model Number

T10225(PLT-16.5-V-840-BYP)
