R4S7950120WB

High Performance LEDS up to 90 lm/w

Use to replace up to 85W traditional light sources

Robust plastic construction

UL wet location rated

Compatible with most standard recessed housings

Dimmable down to 5% on compatible dimmers

Available in Square 4" 650lm and 6" 950lm

Available in 4 color temperatures: 2700K, 3000K, 3500K, 4000K & 5000K

Available in a baffle trim option

Color designer trims as optional accessories available

5-Year, No-Compromise Warranty

View Technical Specs

View Price & Availability

Performance

Watts	7W
Color Temp	5000K
Lumens	620 lm
Efficacy	85.7
Color Accuracy	90 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current
120V	60
208V
240V
277V
Input Watts	7W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 0.5 lbs

Technical Specifications

Performance

Product Type

Retrofit

Lumens

600lm

Efficacy

85.7lm/W

Lifespan

50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Wattage Equivalency

Equivalent to 50W Incandescent

LED Characteristics

LEDs

LED array provides a uniform source with high efficiency and no pixilation

Color Accuracy (CRI)

90 CRI

Color Temperature

5000K

Electrical

THD

≤20%

Power Factor

≥0.9

Dimmable

TRIAC and ELV (at 120V only).

Input Voltage

120V

Operating Frequency

60Hz

Operating Temperature

-30°C - 40°C

Other

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Construction

Size

Shape

Square

Housing Material

Plastic

Finish

White

Trim Style

Baffle

Gaskets

Achieve restrictive airflow requirements without additional caulking
