RDLED2S8-40YN-TW

8W replaces 50W MR16 with energy savings of 82%

TRIAC dimmer compatibility for additional light control

Precision-engineered optics deliver smooth light without hot spots or glare

View Technical Specs

View Price & Availability

Performance

Watts	8W
Color Temp	3500K (Warm Neutral)
Lumens	650 lm
Efficacy	73.9 lm/W
Color Accuracy	82 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current
120V	0.08A
208V
240V
277V
Input Watts	8.8W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 1.3 lbs

Technical Specifications

Compliance

UL Listed

Suitable for wet locations in a covered ceiling

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Construction

IC Rated

Suitable for direct contact with insulation

Trim Component

This component can be ordered with New Construction housing in order to make a complete fixture.
See here for New Construction Housing

Maximum Ambient Temperature

Suitable for use in up to 40°C (104°F)

Cold Weather Starting

The minimum starting temperature is -40°C (-40°F)

Lens

Nanostructure lens eliminates "hot spots", and helps provide smooth, uniform light and higher efficiency

Junction Box

Integral junction box with wiring capacity for
Min 60°C supply conductors
End of Run

Housing

Specification-grade, die-cast aluminum construction

Installation

Torsion springs easily install into ceiling collar (remodeler) or rough-in (new construction)

Trim Ring

White powder coated die cast 1/2" trim ring

Green Technology

Mercury and UV free. RoHS-compliant components.

Finish

Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color

Performance

Lifespan

50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Wattage Equivalency

Equivalent to 50W MR16

LED Characteristics

LED

High-output, long-life LED with 2-step binning and integrated driver technology

Color Consistency

2-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Electrical

Driver

Constant Current, Class 2, 120VAC Only, 50/60Hz, 200mA, 0.07A

Dimming Driver

TRIAC and ELV (at 120V only).
See dimmer compatibility guide here.

Optical

Optics

40° beam spread with specular thermoplastic optics

Spacing Criteria

0 to 180° (along): 0.66
90 to 270° (across): 0.66
diagonal: 0.72

Other

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Buy American Act Compliance

RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
