• Ideal for entrance roadways, collector roads, and single-sided roads
  • 27 year lifespan dramatically reduces maintenance and re-lamping costs
  • Precision optics deliver maximum downward street side lumens with uniformity and minimal glare
  • Industry-leading 5G vibration rating per ANSI C136.31
  • Easy-access electrical compartment makes wiring fast and secure
  • 10-Year, No-Compromise Warranty
View Technical Specs
Performance
Watts 105W
Color Temp 3000K (Warm)
Lumens 12,528 lm
Efficacy 117.7 lm/W
Color Accuracy 71 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V 0.89A
208V 0.58A
240V 0.50A
277V 0.44A
Input Watts 106.4W
Dimensions
Link to Dimension Drawing

Weight: 33.5 lbs

Technical Specifications
Compliance
UL Listed
Suitable for wet locations as a downlight
DLC Listed
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities.
DLC Product Code: P0000177Y
IP Rating
Ingress protection rating of IP66 for dust and water
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Construction
IES Classification
The Type II distribution is ideal for entrance roadways, collector roads and other long, single-sided and narrow lighting applications. This type of lighting is commonly found on smaller local streets.
Effective Projected Area
EPA = 2.2
Electrical
Drivers
Two Drivers Constant Current, Class2, 1400mA, 100-277V, 50/60Hz, 0.8A, Power Factor 99%
THD
5.9% at 120V, 11.9% at 277V
Power Factor
99.6% at 120V, 94.4% at 277V
