SHARK4-36NW/480

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

SHARK4-36NW/480

Impact-resistant linear washdown

Ideal for tunnels and stairwells

Mounting options: Chain, junction box, angled surface mount or vandal-resistant surface mount

IP66 Rating protects against dust & water ingress

5-Year, No-Compromise Warranty

100,000-Hour LED lifespan

View Technical Specs

View Price & Availability

Performance

Watts	36W
Color Temp	4000K (Neutral)
Lumens	4,110 lm
Efficacy	112 lm/W
Color Accuracy	74 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V
208V
240V
277V
Input Watts	36.7W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 12.2 lbs

Technical Specifications

Compliance

UL Listed

Suitable for wet locations

NSF

NSF Certified by Public Health and Safety

IP Rating

Ingress protection rating of IP66 for dust and water

NEMA Rating

NEMA 4X rating indicates an enclosure protects against windblown dust and rain, splashing and hose-directed water, and offers additional corrosion resistance.

Construction

Reflector/Tray

Aluminum

Housing

5VA impact-resistant polycarbonate. 1/2" openings for conduit and bushing/cord entry. Polycarbonate is affected by cleaning agents or other liquids containing partial solvents such as low molecular weight aldehydes and ethers, ketones, esters, aromatic hydrocarbons and perchlorinated hydrocarbons. Click here for a detailed list of damaging chemicals.

Lens

Diffuse polycarbonate lens for low glare and maximum protection

Installation

Mounting

Quick-mount, surface, stainless steel spring clips supplied. 4 additional mounting accessory kits available.

LED Characteristics

LEDs

Long-life, high-efficacy, surface-mount LEDs

Electrical

Driver

Class 2 Constant Current, 4kV, 347-480VAC, 50-60Hz
