SHARK8-70YNW/D10/LCS

Spec Sheet IES File LM79 Instructions Master Specification Features Spec Sheet EZ Layout

American Bureau of Shipping (ABS) approved

Ideal for tunnels and stairwells

Mounting options:

Chain, junction box, angled surface mount, ceiling mount or vandal-resistant surface mount

IP66 AND NEMA 4X ratings protect against dust, water ingress & corrosion

5-Year, No-Compromise Fixture Warranty and 10-Year, No-Compromise Lightcloud Warranty

100,000-Hour LED lifespan

Built in support Lightcloud_

Easy setup - simply power on, confirm device connectivity and call 844-LIGHTCLOUD

View Technical Specs

View Price & Availability

Performance

Watts	70W
Color Temp	3500K (Warm Neutral)
Lumens	10,026 lm
Efficacy	144.5 lm/W
Color Accuracy	87 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	0.62A
208V	0.38A
240V	0.33A
277V	0.28A
Input Watts	69.4W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 24.5 lbs

Technical Specifications

Installed with Lightcloud

Lightcloud is a commercial wireless lighting control system fully developed and supported by RAB. It's powerful and flexible, yet easy to use and install.

Learn More

Lightcloud

Lightcloud Sensor Installed

Occupancy, vacancy, and closed loop daylight harvesting in one versatile sensor. In addition control any fixture in your Lightcloud integrated/embedded networked lighting luminaire-level control system. LLLC - capable of switching, 0-10Vdimming, power/energy monitoring. Can also be used to extend the range of the Lightcloud mesh network communication protocols.
DLC system - N1XMLOEATBA
Learn more at www.lightcloud.com

Compliance

UL Listed

Suitable for wet locations

UL 94

5VA flame classification

NSF

NSF Certified by Public Health and Safety

IP Rating

Ingress protection rating of IP66 for dust and water

NEMA Rating

NEMA 4X rating indicates an enclosure protects against windblown dust and rain, splashing and hose-directed water, and offers additional corrosion resistance.

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

DLC Listed

This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PVR346SS (Stairwell and Passageway Luminaires)
DLC Product Code: PF5259DJ (High-Bay Luminaires for Commercial and Industrial Buildings)
DLC Product Code: P10LGNGH (Direct Linear Ambient Luminaires)

Construction

Length

8 ft

Reflector

Specular polycarbonate

Housing

IK09 impact-resistant polycarbonate with 5VA flame rating*
1/2" openings for conduit and bushing/cord entry
*Polycarbonate is affected by cleaning agents or other liquids containing partial solvents such as low molecular weight aldehydes and ethers, ketones, esters, aromatic hydrocarbons and perchlorinated hydrocarbons. Click here for a detailed list of damaging chemicals.

Lens

Textured, diffuse polycarbonate lens for low glare and maximum protection

Gaskets

EVA

Cold Weather Starting

The minimum starting temperature is -22°F (-30°C)

Maximum Ambient Temperature

Suitable for use in up to 104°F (40°C)

Finish

Formulated for high durability and long-lasting color

Cord

Comes standard with 6 ft cord

Installation

Mounting

Quick-mount, surface, stainless steel spring clips and V-Hook with bracket screws are supplied. 3 additional mounting accessory kits available.

LED Characteristics

LEDs

Long-life, high-efficacy, surface-mount LEDs

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Electrical

Driver

Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.62A, 208V: 0.34A, 240V: 0.30A, 277V: 0.29A

THD

1.06% at 120V, 3.5% at 277V

Power Factor

99.8% at 120V, 94.3% at 277V

Surge Protection

4 kV

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Other

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
