Performance
| Watts | 9W |
| Color Temp | 3500K (Warm Neutral) |
| Lumens | 744 lm |
| Efficacy | 81.8 lm/W |
| Color Accuracy | 87 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | 0.08A |
| 208V | |
| 240V | |
| 277V | |
| Input Watts | 9.1W |
Dimensions
Weight: 1.0 lbs
Technical Specifications
Compliance
UL Listed
Suitable for damp locations. For indoor use only.
LED Characteristics
LEDs
120V long-life LEDs with integrated driver technology and TRIAC and ELV dimming down to 5%. See compatibility guide here. Power Factor 99.3%, 3 kV surge protection
Color Consistency
3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Construction
Housing
Precision die-cast aluminum construction
Lens
Vandal resistant polycarbonate diffusion lens
Finish
Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color
Installation
Mounting
Simple slide-n-lock mounting bracket mounts to 3 1/2" and 4" round or octagon boxes with mounting screws 2 3/4" and 3 1/2" on center
Electrical
THD
13.9% at 120V
