STL200-LED - RAB Lighting

STL200-LED

Spec Sheet Instructions Spec Sheet

STL200-LED large main

STL200-LED

Compatible with LED lamps

Temperature compensation

Radio frequency immunity

6000 volt surge protection

LED detection & "on guard" indicator

Color matched vandal resistant lens and grill

Protected manual override with auto reset

Can be wired in parallel

View Technical Specs

View Price & Availability

Dimensions

Link to Dimension Drawing

Weight: 1.0 lbs

Technical Specifications

Compliance

UL Listed

Raintight Photoelectric Switch

Electrical

Switching Capacity

8 amps

Voltage

120V
300W LED

Surge Protection

I.E.C specs

Sensor Settings

Detection Pattern

50' x 200°

Time Adjustment

5 seconds to 12 minutes

Power Consumption

1 watt

Other

Warranty

10-year sensor warranty
