• 30,000-Hour LED lifespan
  • 2-year, limited warranty
  • 8 per case, must order in case quantity increments
View Technical Specs
Performance
Watts 40W
Color Temp 5700K
Lumens 2,953 lm
Efficacy 75.7 lm/W
Color Accuracy 85 CRI
L70 Lifespan 30,000 Hours
Type Constant Current
120V 0.33A
208V 0.20A
240V 0.17A
277V 0.15A
Input Watts 39W
Dimensions
Link to Dimension Drawing

Weight: 5.9 lbs

Technical Specifications
Compliance
UL Listed
Suitable for damp locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
Trade Agreements Act Compliant
This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act
LED Characteristics
LEDs
Long-life, high-efficiency, surface-mount LEDs
Performance
Lifespan
30,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Construction
Lens
Frosted polystyrene
Operating Temperature
-20°C (-4°F) to 40°C (104°F)
Housing
Plastic frame & galvanized steel back housing
Installation
Standard integral T-bar clips secure the fixture to T-bars and prevent T-system separation
Finish
Formulated for high durability and long-lasting color
Installation
Mounting
Recessed ceiling
Electrical
Driver
Constant Current, Class 2, 50/60 Hz, 120-277V, 120V: 0.33A, 208V: 0.20A, 240V: 0.17A, 277V: 0.15A
THD
8.66% at 120V, 15.07% at 277V
Power Factor
99.1% at 120V, 95.8% at 277V
