T34-2X4-40N/D10

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

T34-2X4-40N/D10

Integrated 0-10V dimming

50,000-Hour LED lifespan

5-Year, limited warranty

2 per case, must order in case quantity increments

View Technical Specs

View Price & Availability

Performance

Watts	40W
Color Temp	4000K (Neutral)
Lumens	4,472 lm
Efficacy	113
Color Accuracy	80 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current
120V	0.33A
208V	0.20A
240V	0.17A
277V	0.15A
Input Watts	39.6W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 8.9 lbs

Technical Specifications

Compliance

UL Listed

Suitable for damp locations

IC Rated

Suitable for direct contact with insulation

CCEA Compliant

Luminaire Requirements used in Environmental Air Space per the electrical code specification of the City of Chicago

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Trade Agreements Act Compliant

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

DLC Listed

This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.

LED Characteristics

LEDs

Long-life, high-efficiency, surface-mount LEDs

Performance

Lifespan

50,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Electrical

Driver

Constant Current, Class 2, 120-277V, 50/60 Hz, 2kV surge protection, 120V: 0.33A, 208V: 0.20A, 240V: 0.17A, 277V: 0.15A

THD

10.9% at 120V, 10.01% at 277V

Power Factor

98.8% at 120V, 95.1% at 277V

Dimming

0-10V, standard down to 10%

Construction

Operating Temperature

-4°F(-20°C) to 104°F (40°C )

Lens

Frosted polystyrene

Housing

Plastic frame & galvanized steel back housing

Finish

White

Green Technology

Mercury and UV free. RoHS-compliant components.

Installation

Mounting

Recessed into T-grid ceiling. Surface and recessed mounting kits available for drywall ceilings.

Other

5-Year Limited Warranty

The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
