T5-25-48G-830-BYP

Spec Sheet LM79 Instructions FCC Caution Family Spec Sheet Spec Sheet

T5-25-48G-830-BYP

Replacement for conventional fluorescent tubes

Integral Driver enables lamp to be wired directly to line voltage without need for an external driver or ballast

Double ended wiring method

50,000 hour Lifespan

Rated for use in enclosed and open fixtures in dry or damp locations

Diffused frosted lens will maintain the same light quality over time

Instant on full brightness

Environmentally friendly, no mercury used

NSF Listed: NSF/ANSI Standard 2 - Food Equipment - Splash Zone (Not for Direct Food Zone without additional fixture considerations)

UL Classified, DLC Listed

Emergency back up available. Catalog Numbers: DRI-5-EMGR-T8, DRI-10-EMGR-TYPE B

Compatible with RAB specified 0-10V dimming system

View Technical Specs

View Price & Availability

Performance

Watts	25W
Color Temp	3000K (Warm White)
Lumens	3,300 lm
Efficacy	132 lm/W
Color Accuracy	82 CRI
L70 Lifespan	50,000 Hours

Input Voltage	120-277
Power Factor	0.9
Flicker	N/A
THDi	N/A

Dimensions

Weight: 0.5 lbs

Technical Specifications

Performance

Product Type

Linear

Input Wattage

25W

Lumens

3,300lm

Efficacy

132lm/W

L70 Lifespan

50,000 Hours

Wattage Equivalency

54W Fluorescent

Construction

Material

Glass

Shape

Nominal Length

4 ft

Finish

Frosted

For Use Outdoors in Open Fixtures

LED Characteristics

Color Temperature

3000K Warm White

Color Accuracy (CRI)

82 CRI

Beam Angle

180°

Installation

Base Type

Electrical

THD

<20%

Power Factor

0.9

Operating Temperature

-20°C to 45°C (-4°F to 113°F)

Dimming

Input Voltage

120-277V AC

Operating Frequency

50/60Hz

Other

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Compliance

UL Recognized

Yes

UL Classified

Yes

NSF Listed

Meets NSF/ANSI standards for use in Food Zone (non-contact), Splash, and Non-Food Zones. Tube guard required in open fixtures.

Certification Model Number

T5-25-48G-830-BYP

California Energy Commission (CEC) Status

Lawful for Sales in California

Application

Suitable for damp locations and totally enclosed fixtures.

DLC Listed

This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.
