T5HE-9-36G-835-DIR

Direct Replacement for conventional fluorescent tubes

Easy to install plug and play that requires no rewiring, no tools, no instructions

50,000 hour Lifespan

Rated for use in enclosed and open fixtures in dry or damp locations

Diffused frosted lens will maintain the same light quality over time

Compatible with most program start electronic T5 ballasts, Please check Compatibility List.

Instant on full brightness

Environmentally friendly, no mercury used

NSF Listed: NSF/ANSI Standard 2 - Food Equipment - Splash Zone (Not for Direct Food Zone without additional fixture considerations

UL Listed

Compatible with RAB specified 0-10V dimming system

View Technical Specs

View Price & Availability

Performance

Watts	9W
Color Temp	3500K
Lumens	1,300 lm
Efficacy	144
Color Accuracy	80 CRI
L70 Lifespan	50,000 Hours

Input Voltage	120-277V
Power Factor	>0.9
Flicker	N/A
THDi	<20%

Dimensions

Weight: 0.3 lbs

Technical Specifications

Performance

Product Type

Linear

Input Wattage

Lumens

1,300lm

Efficacy

144lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Wattage Equivalency

F21T5

LED Characteristics

Color Accuracy (CRI)

Color Temperature

3500K

Beam Angle

160°

Electrical

THD

≤20%

Power Factor

>0.9

Dimmable

Yes

Operating Temperature

-20°C to 45°C

Input Voltage

120-277V

Operating Frequency

50/60Hz

Dimming

Yes with 0-10V dimmer + ballast. See Dimmer Compatibility List.

Construction

Nominal Length

3 ft

Bulb Shape

Enclosure Material

Glass

Housing Finish

Aluminum

Lens Finish

Frosted

Installation

Base Type

Installation Method

UL Type A, Plug and Play

Other

Technology EQ

Fluorescent

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Compliance

Listings

UL Listed

Environment

Damp / Enclosed

NSF Listing

NSF/ANSI Standard 2 - Food Equipment (non-contact), Splash Zone, and Non-Food Zone. (Not for Direct Food Zone without additional fixture considerations)

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15B of the FCC Rules
