TNF/LCB

Non-pixelated light diffusion enables the product to be freely bent in any direction, vertically or horizontally

Field-cuttable for shorter runs with a max run of 32ft. Can be linked with connectors (sold separately)

Easy installation with clips, fixed channel, and bendable channel (sold separately)

Tunable white 2700-6500K, requires Lightcloud Blue controller (sold separately)

Indoor or outdoor rated drivers available (sold separately)

50,000-hr rated life, Title 24 Compliant, and 5-year limited warranty

View Technical Specs

View Price & Availability

Performance

Watts	2.5W/ftW
Color Temp	2700-6500K
Lumens	135lm/ft lm
Efficacy
Color Accuracy	90 CRI
L70 Lifespan	50,000 Hours

Type	Constant Voltage
120V
208V
240V
277V
Input Watts	2.5W/ftW

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 3.2 lbs

Technical Specifications

Lightcloud

Factory Reset

See LCBLV/TW on rablighting.com

Performance

Product Type

16 ft Dual flex silicone neon tape light tunable white - Wet rated

Description

NEOFLEX recreates the look of classic neon with smooth, dot-free illumination. Engineered for indoor and outdoor applications, it is IP67 rated for long-lasting, reliable performance.

Input Wattage

2.5W/ft

Lumens

120lm/ft (WW)
135lm/ft(CW)

Lumens/Foot

135 lm/ft

L70 Lifespan

50,000-Hour LED lifespan based on IES LM-70 results

Electrical

Dimmable

Yes, using Lightcloud Blue
This product will not operate properly when connected to a standard (incandescent) dimmer or dimming control.

Input Voltage

DC24V

Operating Temperature

-4°F to 113°F (-20°C to 45°C)

Storage Temperature

-4°F (-20°C) to 140°F(60°C)

LED Characteristics

Beam Angle

120°

Color Temperature

Default: 3000K
Tunable white 2700-6500K using Lightcloud Blue

Color Accuracy (CRI)

90 CRI

R9 Value

High color performance with R9 greater than 60

Color Consistency

<5-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Field Cuttable Increment

Cuttable every 2"

LED Segments per Reel

100

Chip Density

73 LED/ft

Installation

Mounting

Easy installation with clips, fixed channel, and bendable channel (sold separately)

Construction

Reel Length

16 ft

Max Run Length

32 ft

Length

16.4 ft

PCB Width

Width: 16mm
Height: 16mm

Light Source

COB LED White

Material Construction

Single-axis top-bend design for controlled curved installations.

Light Effect

Soft linear lighting performance

Spool Length

16.4 ft

Bendable

Top bend

Compliance

Listings

UL2108

Environment

Suitable for use indoors and outdoors in dry, damp, or wet environments.

IP Rating

IP67

California Title 24 JA8 Compliant

Can be used to conform with the requirements of California Title 24 Part 6.

California Energy Commission (CEC) Status

Lawful for Sales in California

NEC Compliant

Suitable for use in closets when used in an enclosed extrusion based on NFPA 70, NEC section 410.16 (A)(1) and 410.16 (C)(1)

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15 of the FCC Rules

Other

Compatible Products

LCBLV/TW
Lightcloud Blue controller for tunable white tape light

Field Wiring Accessories

TPF3NF
3-Pin Power Feed Kit

Mounting Accessories

TAP16
16mm Wide Aluminum Straight Channel

TAP16TL
Trimless 16mm Wide Aluminium Profile

TSG
Silicone glue

TB16
16mm Wide Mounting Brackets

TBB16
16mm Wide Bendable Aluminum Channel

Compatible Drivers

TND-96
96W Indoor/Outdoor Driver ON/OFF

5-Year Limited Warranty

The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
