VAN1LED12YW

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

VAN1LED12YW

Vandalproof polycarbonate drop lens

Ultra efficiency

Low-profile design

View Technical Specs

View Price & Availability

Performance

Watts	12W
Color Temp	3000K (Warm)
Lumens	1,406 lm
Efficacy	117.2 lm/W
Color Accuracy	84 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current
120V	0.103A
208V
240V
277V
Input Watts	12W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 1.6 lbs

Technical Specifications

Compliance

UL Listed

Suitable for Wet Locations. Covered Ceiling Mount Only.

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

DLC Listed

This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.

Other

Dimmer Compatibility

TRIAC/ELV dimming capable. See dimmer compatibility guide here.

Optional Sensor

VAN1LED is compatible with occupancy sensors. Click here to see all occupancy sensor accessories.

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Construction

Cold Weather Starting

The minimum starting temperature is -22°F (-30°C)

Maximum Ambient Temperature

Suitable for use in up to 113°F (45°C)

Housing

Precision steel housing

Lens

Vandalproof, frosted polycarbonate drop lens

Gaskets

High-temperature silicone gaskets

Finish

Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

Performance

Lifespan

50,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Wattage Equivalency

Equivalent to 70W Metal Halide

LED Characteristics

LEDs

120V long-lfe LEDs

Color Stability

RAB LEDs exceed industry standards for chromatic stability

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Installation

Mounting

Ceiling mount to recessed junction with knockout template. Tamperproof screws.

Electrical

Driver

AC board, 50/60 Hz., 120V: 103 mA

THD

11.2% at 120V

Power Factor

99.4% at 120V

Surge Protection

2.5 kV
