VANLED28YFFRW/PCS2

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

VANLED28YFFRW/PCS2

Fits the footprint of older canopy lights

Vandal resistant and UV resistant lens

Ultra-high efficiency

Clean, contemporary, low-profile design

Available with drop lens or flat lens

IP66 rated, keeps dust, bugs and water out

Photo and motion sensor options available

View Technical Specs

View Price & Availability

Performance

Watts	28W
Color Temp	3000K (Warm)
Lumens	3,491 lm
Efficacy	126.6
Color Accuracy	84 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	0.24A
208V	0.14A
240V	012A
277V	0.11A
Input Watts	27.6W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 11.5 lbs

Technical Specifications

Compliance

UL Listed

Suitable for Wet Locations. Covered Ceiling Mount Only.

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

IP Rating

Ingress protection rating of IP66 for dust and water

DLC Listed

This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PPV15XKG (DLC Premium: Stairwell and Passageway Luminaires)
DLC Product Code: S-PWEU5K (DLC Standard: Canopy Lighting)

Electrical

Driver

Class 2, Constant Current, 120-277V, 50-60Hz, 120V: 0.24A, 208V: 0.14A, 240V: 0.12A, 277V: 0.11A

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

11.14% at 120V, 11.68% at 277V

Power Factor

97.9% at 120V, 94.3% at 277V

Photocell

277V Swivel photocell included. Photocell is compatible with 208V-277V.

LED Characteristics

LEDs

Long-life, high-efficacy, surface-mount LEDs

Color Stability

RAB LEDs exceed industry standards for chromatic stability

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Construction

Maximum Ambient Temperature

Suitable for use in up to 70°C (158°F)

Cold Weather Starting

The minimum starting temperature is -40°C (-40°F)

Lens

Vandal-resistant polycarbonate textured opaque for low glare frosted flat lens

Housing

Die-cast aluminum housing and lens frame with (4) 1/2" NPS side conduit entries and weatherproof rear wire plug and access plate

Air Tight

Housing certified Air Tight as per ASTM E283

Finish

Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color

Installation

Mounting

Ceiling mount to recessed junction with knockout template or directy to ceiling surface, utilizing side conduit entry points

Other

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Performance

Wattage Equivalency

Equivalent to 100W Metal Halide
