VXBRLED26/PCS2

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

VXBRLED26/PCS2

High performance LED light engine

100,000-hour life based on LM-80 results and TM-21 calculations

Die Cast Aluminum Housing

Classic design with state of the art LED technology

View Technical Specs

View Price & Availability

Performance

Watts	26W
Color Temp	4900K (Cool)
Lumens	2,004 lm
Efficacy	73.9 lm/W
Color Accuracy	68 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V
208V	0.14A
240V	0.13A
277V	0.11A
Input Watts	27.1W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 3.7 lbs

Technical Specifications

Electrical

Driver

Constant Current, 100V-277V, 50/60 Hz, 0.48 Amp, Power Factor 97.9%.

Photocell

277V Swivel photocell included. Photocell is compatible with 208V-277V

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Construction

Specification

These specifications are for fixture with Frosted Glass Globe and Die Cast Guard combination. Consult warehouse for different fixture combinations.

Globes and Guards

Vaporproof LEDs are compatible with RAB Globes and Guards

Cold Weather Starting

The minimum starting temperature is -40°C (-40°F)

Ambient Temperature

Suitable for use in up to 40°C (104°F)

Thermal Management (Patent Pending)

Die-cast LED housing designed for maximum heat dissipation

Housing

All die-cast aluminum construction

Gaskets

High-temperature silicone

Finish

Natural shot blasted aluminum

Green Technology

Mercury and UV free. RoHS-compliant components.

Compliance

UL Listed

Suitable for Wet locations only with outer globe and as a Downlight

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

LED Characteristics

LED

Multi-chip 26W high-output, long-life LED

Color Consistency

3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C38.377-2011.

Installation

Mounting

(3) 1/2" NPS conduit entry points

Other

Patents

The design of the LVAPOR is protected by the following patents US pat. pending; D651738 CN ZL201230040341.3; ZL201130028360.X, TW pat. 101301367 MX 35699; pat. pending CA.

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
