W22-M-60W/E
60W 3000/4000/5000K
- 100,000-Hour LED lifespan
- 0-10V dimming standard
- 5-Year, limited warranty
Performance
| Watts | 60/50/40/30W |
| Color Temp | 3000/4000/5000K |
| Lumens | 3,727-9,105 lm |
| Efficacy | 117.1-161.5 lm/W |
| Color Accuracy | 82-85 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant |
| 120V | 0.50A |
| 208V | 0.29A |
| 240V | 0.25A |
| 277V | 0.22A |
| Input Watts | 29.3-61W |
Dimensions
Weight: 9.5 lbs
Technical Specifications
Field Adjustability
Cutoff Adjustability
45°, 30°, 15° and 0° (factory default 45°)
Field Adjustable
Field Adjustable Light Output:
60W/50W/40W/30W (factory default 60W)
Color temperature selectable 3000K, 4000K and 5000K (factory default 4000K)
60W/50W/40W/30W (factory default 60W)
Color temperature selectable 3000K, 4000K and 5000K (factory default 4000K)
Compliance
UL Listed
Suitable for wet locations
DLC Listed
This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.
Electrical
Driver
Constant Current, Class 1, 120-277V, 50/60 Hz:
60W: 120V: 0.50A, 208V: 0.29A, 240V: 0.25A, 277V: 0.22A
50W: 120V: 0.41A, 208V: 0.24A, 240V: 0.21A, 277V: 0.19
40W: 120V: 0.34A, 208V: 0.20A, 240V: 0.18A, 277V: 0.15A
30W: 120V: 0.25A, 208V: 0.15A, 240V: 0.13A, 277V: 0.11A
60W: 120V: 0.50A, 208V: 0.29A, 240V: 0.25A, 277V: 0.22A
50W: 120V: 0.41A, 208V: 0.24A, 240V: 0.21A, 277V: 0.19
40W: 120V: 0.34A, 208V: 0.20A, 240V: 0.18A, 277V: 0.15A
30W: 120V: 0.25A, 208V: 0.15A, 240V: 0.13A, 277V: 0.11A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
Photocell
Integrated photocell included with on/off switch
Surge Protection
DM 4 kV+ CM 6 kV
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Performance Data
Wattage Equivalency
60W: Replaces up to 250W Metal Halide (MH) or 200W High Pressure Sodium (HPS)
50W: Replaces up to 250W Metal Halide (MH) or 200W High Pressure Sodium (HPS)
40W: Replaces up to 175W Metal Halide (MH) or 150W High Pressure Sodium (HPS)
30W: Replaces up to 150W Metal Halide (MH) or 100W High Pressure Sodium (HPS)
50W: Replaces up to 250W Metal Halide (MH) or 200W High Pressure Sodium (HPS)
40W: Replaces up to 175W Metal Halide (MH) or 150W High Pressure Sodium (HPS)
30W: Replaces up to 150W Metal Halide (MH) or 100W High Pressure Sodium (HPS)
Emergency Characteristics
Battery Backup
Battery backup will operate the fixture for 90 minutes if power fails. Wired for 120-277V.
Battery Backup Light Loss Factor
60W: 0.15
50W: 0.18
40W: 0.22
30W: 0.3
50W: 0.18
40W: 0.22
30W: 0.3
LED Characteristics
LEDs
Long-life, high-efficacy, surface-mount LEDs
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Construction
Housing
Die-cast aluminum
Lens
Glass
Reflector
Aluminum
Cold Weather Starting
The minimum starting temperature is 32°F/0°C Ambient Temperature
Maximum Ambient Temperature
Suitable for use in up to 122°F (50°C)
Green Technology
Mercury and UV free. RoHS-compliant components.
Finish
Formulated for high durability and long-lasting color
Installation
Mounting
Suface mount for recessed junction box; 3 conduit entry points
Optical
BUG Rating
60W: B2 U4 G5
50W: B2 U4 G4
40W: B1 U3 G4
30W: B1 U3 G3
50W: B2 U4 G4
40W: B1 U3 G4
30W: B1 U3 G3
Other
5-Year Limited Warranty
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
