WFRL4R99FA120WBS

Spec Sheet IES File CutOut Template Dimmer Compatibility List Downlight Accessory Compatibility List LM79 Instructions Cut Out Template Sell Sheet Family Spec Sheet Spec Sheet EZ Layout

WFRL4R99FA120WBS

5 color temperatures in 1 SKU (2700K, 3000K, 3500K, 4000K, 5000K)

Super slim back-lit fixture for thin fixture depth

Suitable for indoor/outdoor applications in dry, damp, or wet environments

Dimmable, see Dimmer Compatibility List

Robust, die cast aluminum construction

Smooth diffused uniform light distribution

View Technical Specs

View Price & Availability

Performance

Watts	9W
Color Temp	Field Adjustable: 2700K/3000K/3500K/4000K/5000K
Lumens	650 lm
Efficacy	72
Color Accuracy	90 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current
120V	.10A
208V
240V
277V
Input Watts	9W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 0.8 lbs

Technical Specifications

Performance

Product Type

Back-Lit Wafer

Description

Field selectable color temperatures in one wafer with an ultra shallow depth for recessed mounting.

Wattage Equivalency

60W Incandescent

Lumens

2700K @ 650lm;
3000K @ 665lm;
3500K @ 675lm;
4000K @ 680lm;
5000K @ 675lm

Efficacy

2700K @ 72lm/W;
3000K @ 74lm/W;
3500K @ 75lm/W;
4000K @ 76lm/W;
5000K @ 75lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IES LM-70 results

Electrical

Driver

Constant Current, Class 2, 50/60 Hz 120V, 120V: 0.10 A

THD

≤20%

Power Factor

≥0.9

Dimmable

Yes, TRIAC, dims down to 10%. See Dimmer Compatibility List

Input Voltage

120V

Operating Frequency

60 Hz

Operating Temperature

-4°F to 104°F (-20°C to 40°C)

Flicker

≤5%

LED Characteristics

Color Temperature

Field Adjustable dip switch 2700K/3000K/3500K/4000K/5000K

Color Accuracy (CRI)

>90 CRI

R9 Value

High color performance with R9 greater than or equal to 50

Color Consistency

4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Installation

Mounting

Recessed Housing

Construction

Size

Shape

Round

Finish

White

Housing Material

Metal and Plastic

Trim Style

Baffle

Gaskets

Gasket included can achieve restrictive airflow and wet location without any additional gasket or caulk

Lens

Acrylic light guide distributes light evenly and smoothly for general lighting applications

Beam Angle

110°

Remote Driver

Stamping formed galvanized steel driver / junction box with captive hinged junction box cover.
Recessed CCT Selectable dip-switch.
Listed for (6) #12 AWG 90° C splice conductors
2-in, 2-out plus 2-ground
(4) 1/2" conduit pry-outs
(3) Push in connectors for quick and reliable line voltage connections. Integral mounting facilitates direct mounting to building structure or mounting frame.

Cut Out Template Size

4 5/16"

IC Rated

Suitable for direct contact with insulation

Compliance

Listings

UL Listed

Environment

Suitable for use in dry, damp, and wet environments.

Air Tight

Housing certified Air Tight as per ASTM E283

Energy Star Approved

This product is ENERGY STAR® Version 2.2 Certified

Energy Star ID

2401349

Certification Model Number

DLW0094(WFRL4R99FA120WBS)

T20 Compliant

Not compliant

California Title 24 JA8 Compliant

Can be used to conform with the requirements of California Title 24 Part 6

California Energy Commission (CEC) Status

Lawful for Sales in California

NEC Compliant

Suitable for use in closets. Compliant with NEC Sec. 410.16 (A)(1) and 410.16 (C3).

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15B of the FCC Rules

Trade Agreements Act Compliant

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

Other

Compatible Products

DRI-25-EMGR-DC
25W Emergency Driver
HAD4/D10
120-277V driver 0-10V dimming

Accessories

WFRL-TRIM-4R-BS
4" Black Smooth Trim
WFRL-TRIM-4R-BRS
4" Bronze Smooth Trim
WFRL-TRIM-4R-BNS
4" Brushed Nickel Smooth Trim
WFRL-GOOF-4R-6R-W
4"-6" Goof Ring
DLPLATE/WFR3468/NB
3"/4"/6"/8" Mounting Plate
EXTCBL-FA-6
6' Extension Cable
EXTCBL-FA-12
12' Extension Cable
EXTCBL-FA-20
20' Extension Cable

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Note

All values are typical (tolerance +/- 10%)

Buy American Act Compliance

RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
