WFRL4R99TW120WB-SS-NS/LCB

Spec Sheet IES File Downlight Accessory Compatibility List LM79 Instructions Family Spec Sheet Spec Sheet EZ Layout

Direct connect to the Lightcloud Blue mobile app via Bluetooth; no Gateway or Hub required

Use mobile device to configure features for On/Off Control, Dim Level, Color Temperature, Schedules, Scenes, SmartShift and more

Tunable White 2700 - 6500K with smooth transition between color temperatures

SmartShift technology syncs with local sunrise/sunset for healthier circadian lighting

Natural Spectrum technology mimics natural light that renders color accurately

View Technical Specs

View Price & Availability

Performance

Watts	9W
Color Temp	Tunable White 2700K - 6500K
Lumens	550 lm
Efficacy	61
Color Accuracy	95 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current, Class 2
120V	.08A
208V
240V
277V
Input Watts	9W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 1.0 lbs

Technical Specifications

Performance

Product Type

Edge-Lit Wafer

Description

This canless wafer has an ultra low profile design making them a flexible solution for both new construction and retrofit applications. With museum quality CRI and Lightcloud Blue-enabled features this is the ideal solution for museums, galleries, residential, and retail applications.

Wattage Equivalency

60W Incandescent

Input Wattage

Lumens

550lm

Efficacy

61lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IES LM-70 results

Lightcloud

Lightcloud Blue

Lightcloud Blue is a Bluetooth mesh wireless lighting control system that allows you to control RAB's various compatible devices. With RAB's patent-pending Rapid Provisioning technology, devices can be quickly and easily commissioned for residential and large commercial applications using the Lightcloud Blue mobile app. Each device in a system can communicate with any other device, eliminating the need for a Gateway or Hub and maximizing the control system's reach.
Learn more at www.lightcloud.com

Gateway Required

Communication Protocol

Bluetooth Mesh

SmartShift

SmartShift is the most advanced - yet easiest to use - circadian lighting system, which syncs white color tuning with the local sunrise and sunset.

Range

Up to 60 feet between standard building materials. Building materials such as brick, concrete, and steel construction may require additional Lightcloud Blue devices to extend around an obstruction.
Up to 200 feet clear line of sight (varies by device).

Spacing Criteria

Lightcloud Blue devices should be placed within the specified range to communicate within the Bluetooth Mesh network.

Factory Reset

Method 1: Delete from App
Open the app and access the device settings for the paired device. Be sure that the downlight is online and select 'Delete'.
Method 2: Manual
Power the downlight off and on 5x consecutively. Do not allow less than 4s to elapse from switching off to on. Do not allow more than 2s to elapse from switching on to off. The downlight will flash 3x, then reset to 100% brightness at default CCT.
Method 3: Rapid Reset Tool
The Rapid Reset process must be done by a professional electrician qualified by RAB. Reach out to your RAB sales manager to request a Rapid Reset Tool. The tool simply needs to be placed directly on the small Lightcloud Blue logo on the device for 2s or until the lamp/luminaire flashes 3x, then resets to 100% brightness at the default CCT.

Electrical

Driver

Constant Current, Class 2, 60 Hz, 120V, 120V: 0.08A

THD

≤20%

Power Factor

≥0.9

Dimmable

Yes, via the Lightcloud Blue mobile app and devices.
This lamp will not operate properly when connected to a standard (incandescent) dimmer or dimming control.

Input Voltage

120V

Operating Frequency

60 Hz

Input Current @ 120V (mA)

82mA

Operating Temperature

-4°F to 104°F (-20°C to 40°C)

Flicker

≤5%

LED Characteristics

LEDs

Edge-lit

Color Temperature

Tunable White 2200K - 6500K

Color Accuracy (CRI)

>95 CRI

Natural Spectrum

Low blue LEDs deliver a spectrum of light similar to that of natural Sunlight. They beautifully render colors with greater than 95+ CRI and an R9 value greater than 90. In addition, these LEDs don't suppress melatonin creation which aids in promoting better sleep/wake cycles.

R9 Value

High color performance with R9 greater than or equal to 50

Color Consistency

4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Installation

Mounting

Recessed Housing

Construction

Size

Shape

Round

Finish

White

Housing Material

Metal and Plastic

Trim Style

Baffle

Gaskets

Gasket included can achieve restrictive airflow and wet location without any additional gasket or caulk

Lens

Acrylic light guide distributes light evenly and smoothly for general lighting applications

Beam Angle

110°

Remote Driver

Stamping formed galvanized steel driver / junction box with captive hinged junction box cover.
Recessed CCT Selectable dip-switch.
Listed for (6) #12 AWG 90°C splice conductors.
2-in, 2-out plus 2-ground.
(4) 1/2" conduit pry-outs.
(3) Push in connectors for quick and reliable line voltage connections. Integral mounting facilitates direct mounting to building structure or mounting frame.

IC Rated

Suitable for direct contact with insulation

Compliance

Listings

UL Listed

Environment

Suitable for use in dry, damp, and wet environments.

Air Tight

Not compliant

Energy Star Approved

This product is ENERGY STAR® Version 2.2 Certified

Energy Star ID

2404279

T20 Compliant

Not compliant

California Title 24 JA8 Compliant

Can be used to conform with the requirements of California Title 24 Part 6

California Energy Commission (CEC) Status

Lawful for Sales in California

NEC Compliant

Suitable for use in closets. Compliant with NEC Sec. 410.16 (A)(1) and 410.16 (C3).

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15B of the FCC Rules

Trade Agreements Act Compliant

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

Other

Accessories

HAD4/D10
277V 0-10V driver
DLPLATE/WFR3456
Mounting plate
DLPLATE/WFR3468/NB
Mounting plate with nailer bar
WFRL-GOOF-4R-6R-W
4"- 6" Goof Ring
WFRL-TRIM-4R-BS
4" round smooth black trim
WFRL-TRIM-4R-BRS
4" round smooth bronze trim
WFRL-TRIM-4R-BN
4" round smooth brushed nickel trim
EXTCBL-CCT-6
6' Extension cable
EXTCBL-CCT-12
12' Extension cable
EXTCBL-CCT-20
20' Extension cable

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Note

All values are typical (tolerance +/- 10%)

Buy American Act Compliance

RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
