• 5 color temperatures in 1 SKU (2700K, 3000K, 3500K, 4000K, 5000K)
  • Super slim Edge-lit fixture for thin fixture depth
  • No recessed housing or J-box required
  • New construction or retrofit applications
  • UL wet location rated
  • Smooth diffused uniform light distribution
  • Dimmable down to 5% on compatible dimmers
  • Spring loaded retention clips
  • Robust, die cast aluminum construction
  • IC and airtight rated
  • 5-Year, No-Compromise Warranty
View Technical Specs
Performance
Watts 13W
Color Temp Field Adjustable
Lumens 1,007 lm
Efficacy 73
Color Accuracy 90 CRI
L70 Lifespan 50,000 Hours
Type Constant Current
120V 0.13A
208V
240V
277V
Input Watts 13W
Dimensions
Link to Dimension Drawing

Weight: 0.2 lbs

Technical Specifications
Performance
Product Type
Wafer Direct Mount
LEDs
Edge-lit LED Technology
Input Wattage
13W
Lumens
1,000lm | 1,045lm | 1,100lm | 1,130lm | 1,130lm
Efficacy
77lm/W | 80.4lm/W | 84.6lm/W | 86.9lm/W | 86.9lm/W
L70 Lifespan
50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Wattage Equivalency
75W
LED Characteristics
Color Temperature
Field Adjustable dip switch 2700K/3000K/3500K/4000K/5000K
Color Accuracy (CRI)
90 CRI
Electrical
THD
≤20%
Power Factor
≥0.9
Dimmable
TRIAC and ELV dimming compatibility
Operating Temperature
-30°C - 40°C
Input Voltage
120V
Operating Frequency
60Hz
Construction
Size
6"
Shape
Round
Enclosure Material
Plastic
Finish
White
Trim Style
Baffle
Lens
Acrylic light guide distributes light evenly and smoothly for general lighting applications
Gaskets
Gasket included can achieve restrictive airflow and wet location without any additional gasket or calk
Optical
Beam Angle
110°
Installation
Mounting
Tall spring towers allow to be installed in 3/8" up to 5/8" thick ceilings
Round ceiling cutout template provided in box
Heat treated springs hold fixture fitting securely in the ceiling eliminating light leaks
Housing is less than 1/2" thick
Can be removed from below the ceiling for service or replacement
Remote Driver / Junction Box
Die formed metal driver / junction box with captive hinged junction box cover. Recessed CCT Selectable dipswitch. Listed for (6) #12 AWG 90° C splice conductors, 2-in, 2-out plus (2) ground. (4) 1/2" conduit pry-outs. (3) wire nuts for quick and reliable line voltage connections. Integral mounting facilitates direct mounting to building structure or mounting frame.
Other
Technology EQ
Incandescent
Buy American Act Compliance
RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
Compliance
Certification Model Number
DLW0056(WFRL6R139FA120WB)
Listings
UL Listed
Environment
Wet
Fixture Rating
Enclosed
Air Tight
Housing certified Air Tight as per ASTM E283
IC Rated
Suitable for direct contact with insulation
Energy Star ID
2365745
T24 JA8 Compliant
Complies with Title 24 Appendix JA8
NEC Compliant
Suitable for use in closets. Compliant with NEC Sec. 410.16 (A)(1) and 410.16 (C3).
RoHS
Mercury and UV free. RoHS-compliant components.
FCC
Complies with Part 15B of the FCC Rules
Trade Agreements Act Compliant
This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act
