WP1LED39L-750WH
WP1LED39L-750WH large main
  • Affordable wall pack with traditional look
  • Ultra-high efficacy
  • Covers footprint of small HID wall packs
  • 100,000-Hour LED lifespan
 View Technical Specs
View Price & Availability
Performance
Watts 26W
Color Temp 5000K (Cool)
Lumens 3,919 lm
Efficacy 148.4
Color Accuracy 72 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V
208V
240V
277V
Input Watts 26.4W
Dimensions
Link to Dimension Drawing

Weight: 4.5 lbs

Technical Specifications
Compliance
UL Listed
Suitable for wet locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNAlm-79 andlm-80.
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PROO1X0A
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Wattage Equivalency
Equivalent to 100W Metal Halide
LED Characteristics
LEDs
Multip-chip, high-output, long-life LEDs
Construction
Cold Weather Starting
The minimum starting temperature is -40°F (-40°C)
Electrical
Driver
Constant Current, 480V, 50/60 Hz, 480V: 0.05A
THD
3.75% at 480V
Power Factor
91.1% at 480V
