WP3LED75L-730WU/PCU
WP3LED75L-730WU/PCU large main
  • Affordable wall pack with traditional look
  • Ultra-high efficacy
  • Covers footprint of large HID wall packs
  • 100,000-Hour LED lifespan
 View Technical Specs
View Price & Availability
Performance
Watts 51W
Color Temp 3000K (Warm)
Lumens 7,690 lm
Efficacy 159.5
Color Accuracy 72 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V 0.43A
208V 0.25A
240V 0.21A
277V 0.18A
Input Watts 48.2W
Dimensions
Link to Dimension Drawing

Weight: 11.1 lbs

Technical Specifications
Compliance
UL Listed
Suitable for wet locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PUZPRS8I
Performance
Lifespan
100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Wattage Equivalency
Equivalent to 200W Metal Halide
LED Characteristics
LEDs
Multip-chip, high-output, long-life LEDs
Construction
Cold Weather Starting
The minimum starting temperature is -22°F (-30°C)
Electrical
Driver
Constant Current, 120-277V, 50/60 Hz, 120V: 0.43A, 208V: 0.25A, 240V: 0.21A, 277V: 0.18A
THD
9.54% at 120V, 6.14% at 277V
Power Factor
99.1% at 120V, 98.6% at 277V
