• Maintains 70% of initial lumens at 100,000-hours
  • Weatherproof high temperature silicone gaskets
  • Superior heat sinking with die cast aluminum housing and external fins
  • 100 up to 277 Volts
  • 5-Year, No-Compromise Warranty
View Technical Specs
Performance
Watts 26W
Color Temp 5000K (Cool)
Lumens 3,851 lm
Efficacy 134.2 lm/W
Color Accuracy 70 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V 0.22A
208V 0.13A
240V 0.11A
277V 0.10A
Input Watts 28.7W
Dimensions
Link to Dimension Drawing

Weight: 7.2 lbs

Technical Specifications
Electrical
Driver
Constant Current, Class 2, 120-277V, 50/60Hz, 120V: 0.22A, 208V: 0.13A, 240V: 0.11A, 277V 0.10A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
10.68% at 120V, 10.68% at 277V
Power Factor
95.4% at 120V, 95.4% at 277V
Battery Backup
Minimum starting temperature is 0°C/32°F
Battery Backup Light Loss Factor
0.39
Battery Mode
Light output use LLD of.76 to simulate light output during battery mode operation.
Photocell
277V Swivel photocell included. Photocell is compatible with 208V-277V.
Compliance
UL Listed
Suitable for Wet Locations as downlight. Wall Mount Only. Battery Backup UL 924 Listed Emergency Lighting Power Supply.
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: P0000170I
Performance
Lifespan
100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Wattage Equivalency
Equivalent to 150W Metal Halide
LED Characteristics
LED
Two (2) 13W high-output, long-life LEDs
Color Consistency
7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Color Stability
LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Construction
Ambient Temperature
Suitable for use in up to 35°C (95°F)
Thermal Management
Optimized using computational fluid dynamics software to ensure long LED and driver lifespan
Gaskets
High-temperature silicone
Housing
Precision die-cast aluminum housing, lens frame and mounting arm
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Other
Patents
The WPLED26 design is protected by U.S. Patent D634878 and Patents pending in the U.S., Canada, China, Taiwan and Mexico.
Optical
BUG Rating
B1 U0 G0
