WPLED52Y USA
WPLED52Y USA large main
  • High performance LED light engine
  • Maintains 70% of initial lumens at 100,000-hours
  • Weatherproof high temperature silicone gaskets
  • Superior heat sinking with die cast aluminum housing and external fins
  • Replaces 250W MH
  • Traditional wall pack look from the front
  • 3 cutoff options
  • 5-Year, No-Compromise Warranty
 View Technical Specs
View Price & Availability
Performance
Watts 52W
Color Temp 3000K (Warm)
Lumens 7,263 lm
Efficacy 127.2
Color Accuracy 71 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V 0.51A
208V 0.33A
240V 0.29A
277V 0.24A
Input Watts 57.1W
Dimensions
Link to Dimension Drawing

Weight: 18.5 lbs

BAC icon
Technical Specifications
Compliance
UL Listed
Suitable for wet locations
Buy American Act Compliance
This product complies with the Buy American Act
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: P00001740
Electrical
Driver
Constant Current, Class 2, 120-277V, 50-60Hz, 120V: 0.51A, 208V: 0.33A, 240C: 0.29A, 277V: 0.24A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
7.64% at 120V, 5.72% at 277V
Power Factor
99.2% at 120V, 97.5% at 277V
Surge Protection
6 kV
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
LED Characteristics
LEDs
Two (2) multi-chip, high-output, long-life LEDs
Construction
Ambient Temperature
Suitable for use in up to 104°F (40°C)
Cold Weather Starting
The minimum starting temperature is -40°F (-40°C)
Other
FTC Country of Origin
This product was assembled in the USA by RAB using imported components
