WPLEDFC52N/D10
WPLEDFC52N/D10 large main
  • High performance LED light engine
  • Maintains 70% of initial lumens at 100,000-hours
  • Weatherproof high temperature silicone gaskets
  • Superior heat sinking with die cast aluminum housing and external fins
  • Replaces 250W MH
  • Traditional wall pack look from the front
  • 3 cutoff options
  • 5-Year, No-Compromise Warranty
 View Technical Specs
View Price & Availability
Performance
Watts 52W
Color Temp 4000K (Neutral)
Lumens 7,253 lm
Efficacy 129.5 lm/W
Color Accuracy 76 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V 0.52A
208V 0.37A
240V 0.32A
277V 0.28A
Input Watts 56W
Dimensions
Link to Dimension Drawing

Weight: 17.7 lbs

Technical Specifications
Electrical
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
6.24% at 120V, 7.1% at 277V
Power Factor
99.3% at 120V, 97.2% at 277V
Compliance
UL Listed
Suitable for wet locations
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: P0000173D
LED Characteristics
LEDs
Two (2) multi-chip, high-output, long-life LEDs
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-52 results and TM-21 calculations
