A34T3LWMYAW
A34T3LWMYAW
150W Amber
- Wildlife-friendly amber light
- 50,000-hour LED Life
- 0-10V dimming standard
- IP65 rating protects against dust and water
- 5-Year, limited warranty
Performance
| Watts | 150W |
| Color Temp | Amber |
| Lumens | 9,642 lm |
| Efficacy | 59.2 |
| Color Accuracy | |
| L70 Lifespan | 50,000 Hours |
| Type | Constant Current |
| 120V | 1.36A |
| 208V | 0.79A |
| 240V | 0.68A |
| 277V | 0.62A |
| Input Watts | 162.8W |
Dimensions
Weight: 31.8 lbs
Technical Specifications
Compliance
UL Listed
Suitable for wet locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
IP Rating
Ingress protection rating of IP65 for dust and water
DarkSky Approved (Commercial Luminaire)
Commercial Luminaires are outdoor luminaires that are used on properties of commercial or industrial businesses and places with high traffic, such as schools, hotels, and government buildings, as well as public spaces or rights-of-way, including streets and roadways.
DarkSky Approved (Pedestrian Comfort Luminaire)
Pedestrian Comfort Luminaires are commercial luminaires with reduced lumen output and more stringent high-angle light restrictiions that create a more comfortable experience for pedestrians.
DarkSky Approved (Sea Turtle Sensitve Luminaire)
Sea Turtle Sensitive Luminaires include shielding and color spectra tuned to protect specific species habitats (e.g. Sea Turtle Sensitive Luminaires).
DLC Listed
This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.
LUNA
This product has received the Design Lights Consortium's LUNA listing.
LUNA Product Code: S-ML7NFN
LUNA Product Code: S-ML7NFN
Performance
Lifespan
50,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Electrical
Driver
Constant Current, Class 1, Class P, 120-277V; 50/60 Hz; 120V: 1.36A, 208V: 0.79A, 240V: 0.68A, 277V: 0.62A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
Surge Protection
L-L: 6 kV; L/N-G: 10 kV
Photocell
Integrated photocell included with on/off switch
Optical
IES Classification
The Type III distribution is ideal for roadway, general parking and other area lighting applications where a larger pool of lighting is required. It is intended to be located near the side of the area, allowing the light to project outward and fill the area.
BUG Rating
B2 U0 G2
LED Characteristics
LEDs
Long-life, high-efficiency, surface-mount LEDs
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Construction
Cold Weather Starting
The minimum starting temperature is -40°F (-40°C)
Maximum Ambient Temperature
Suitable for use in up to 104°F (40°C)
Lens
Clear polycarbonate lens
Housing
Die-cast aluminum housing, lens frame and mounting arm
Effective Projected Area (EPA)
EPA = 0.2
Vibration Rating
2G
Finish
Formulated for high durability and long-lasting color
Green Technology
Includes recycled plastic and RoHS-compliant components.
Installation
Mounting
Wall mount
Other
5-Year Limited Warranty
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
