RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PKEILEOZ

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Multi-chip, high-output, long-life LEDs

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

-20°C (-4°F) to 50°C (122°F)

22 gauge die formed with white powder coat finish. Y Hooks included for easy chain or cable mounting.

White painted, reflective, die formed painted steel

Polycarbonate lens

V hooks and optional pendant mounting. AEROBAY® comes with two 42" chains.

Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color

Mercury and UV free. RoHS-compliant components.

Integrated/embedded networked lighting control, luminaire-level lighting control. Fixture, Zone, and plug-load control from one powerful device. LLLC - capable of switching, 0-10Vdimming, power/energy monitoring. Can also be used to extend the range of the Lightcloud mesh network communication protocols. Offers the capability to set the maximum light output to a less-than-maximum state of an individual luminaire at the time of installation or commissioning. The High-End trim functionality is field reconfigurable via the Lightcloud mesh network communication protocols. The Lightcloud controller can be attached to the fixture, junction box, or electrical panel.
DLC system - N1XMLOEATBA
Learn more about Lightcloud.

Class 2, Constant Current, 50/60 Hz, 480V: 0.74A

8.96% at 480V

98% at 480V

6kV

Replaces 1000W MH

The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
