BDLEDR18N-32H
BDLEDR18N-32H large main
  • Patented base mount design for super sturdy installation
  • Durable construction and frosted vandal-resistant polycarbonate lens
  • Precision-engineered optics deliver maximum downward lighting without glare
  • Four leveling screws provided for easy installation
  • 100,000-hour LED lifespan
 View Technical Specs
View Price & Availability
Performance
Watts 18W
Color Temp 4000K (Neutral)
Lumens 1,888 lm
Efficacy 108.5 lm/W
Color Accuracy 72 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V 0.24A
208V 0.18A
240V 0.15A
277V 0.12A
Input Watts 17.4W
Dimensions
Link to Dimension Drawing

Weight: 10.4 lbs

Technical Specifications
Compliance
UL Listed
Suitable for wet locations. Suitable for mounting within 4 ft (1.2m) of the ground.
LED Characteristics
LEDs
Long-life, high-efficiency, surface-mount LEDs
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Optical
BUG Rating
B1 U3 G2
Construction
Height
32"
Cold Weather Starting
The minimum starting temperature is -40°F (-40°C)
Thermal Management
Cast aluminum Thermal Management system for optimal heat sinking. The BDLED is designed for cool operation, maximum efficiency and long life by minimizing LED junction temperature.
Electrical
Driver
Constant Current, Class 2, 100-277V, 50/60 Hz, 4kV Surge Protection, 700mA, 120V: 0.24A, 208V: 0.18A, 240V: 0.15A, 277V: 0.12A
THD
6.5% at 120V, 10.4% at 277V
Power Factor
99.5% at 120V, 89.7% at 277V
