DISK34-6

Low-profile, back-lit design made of durable thermoplastic housing with frosted lens

5 Color temperature selectable: 2700K, 3000K, 3500K, 4000K, & 5000K

New construction or retrofit applications

Installs on standard junction boxes

Suitable for indoor/outdoor use in dry, damp, and wet locations

View Technical Specs

View Price & Availability

Performance

Watts	15W
Color Temp	2700/3000/3500/4000/5000K
Lumens	1,000 lm
Efficacy	67
Color Accuracy	90 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current
120V	.14A
208V
240V
277V
Input Watts	15W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 0.5 lbs

Technical Specifications

Performance

Product Type

Disk Surface Mount

Description

Low-profile, surface-mount disk with field-adjustable color temperature for use in dry, damp and wet environments.

Wattage Equivalency

75W Incandescent

Input Wattage

15W

Lumens

2700K @ 1,017lm; 3000K @ 1,077lm; 3500K @ 1,128lm; 4000K @ 1,132lm; 5000K @ 1,088lm

Efficacy

2700K @ 68lm/W; 3000K @ 72lm/W; 3500K @ 77lm/W; 4000K @ 76lm/W; 5000K @ 73lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IES LM-70 results

Electrical

Driver

Constant Current, 60 Hz, 120V, 120V: 0.09A

THD

≤20%

Power Factor

≥0.9

Dimmable

Yes, dimmable down to 10% on compatible TRIAC/ELV dimming systems. See Dimmer Compatibility List.

Input Voltage

120V

Operating Frequency

60 Hz

Input Current @ 120V

136mA

Operating Temperature

-4°F to 104°F (-20°C to 40°C)

Flicker

≤30%

LED Characteristics

Beam Angle

110°±10°

Color Temperature

Field Adjustable dip switch 2700/3000/3500/4000/5000K

Color Accuracy (CRI)

>90 CRI

R9 Value

High color performance with R9 greater than or equal to 50

Color Consistency

4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Installation

Mounting

Surface Mount + Recessed

Construction

Size

Shape

Round

Finish

White

Enclosure Material

Metal

Trim Style

Smooth

Lens

Polycarbonate light diffuser distributes light evenly and smoothly for general lighting applications

Compliance

Listings

UL Listed

Environment

Suitable for indoor and outdoor applications in dry, damp, and wet environments.

IC Rated

Air Tight

T20 Compliant

Not applicable

California Title 24 JA8 Compliant

Can be used to conform with the requirements of California Title 24 Part 6

California Energy Commission (CEC) Status

Lawful for Sales in California

NEC Compliant

Suitable for use in closets. Compliant with NEC Sec. 410.16 (A)(1) and 410.16 (C1).

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

RoHS Compliant

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15B of the FCC Rules

Trade Agreements Act Compliant

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

Energy Star Approved

ENERGY STAR® Version 1.0 Certified

Certification Model Number

DLR0124(R6R149FA120WS)

Other

Accessories

DSKFA6/PIR/ACC
Mounting hardware

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
